Tractor · 2001Unverified
McCormick Intl C50
McCormick Intl C50 — C Series · 40 hp. Reference specifications; pending source verification.
The McCormick Intl C50 is a tractor with a rated power output of 40 hp, categorising it at the lighter end of its class. The C50 was manufactured between the years 2001 and 2003. It features a 3-cylinder diesel liquid-cooled engine paired with four-wheel drive and an 8-speed gearbox. The tractor's operating weight is listed as 5336 to 6063 pounds, and it is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Weight
5336 to 6063 pounds
Catalogue coverage
Variants represented
2
Richest spec table
34 rows
Recorded power
40 hp
Recorded weight
2420 kg
Transmissions
8-speed
Production years
2001-2003
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerMcCormick Intl (a part of Argo)Reference
Utility tractorReference
Built in Doncaster, EnglandReference
Two- or four-wheel driveReference
Engine
Perkins 2.7L 3-cyl dieselReference
Fuel tank120.0 LReference
Engine39.5 kWReference
PerkinsReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke95 x 127 mmReference
Power39.5 kWReference
Rated RPM2250Reference
Torque190.0 NmReference
Torque RPM1200Reference
Starter volts12Reference
Transmission
8-speedReference
16-speedReference
TransmissionsynchromeshReference
Gears8 forward and 4 reverseReference
Clutchdry discReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
PTO (claimed)29.8 kWReference
Typeopen centerReference
Pump flow60.6 lpmReference
Rear lift1661 kgReference
Rear PTO Type540Reference
Dimensions
Weight5336 to 6063 poundsReference
2WD Shipping weight2420 kgReference
4WD Shipping weight2750 kgReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
