The McCormick Intl C70S is a compact tractor with a rated output of 60 hp, characterised by its compact size. It was manufactured from 2005 to 2007. Key features include a 4-cylinder diesel liquid-cooled engine, coupled with a mechanical front-wheel drive system and a 16-speed gearbox. The listed weight is 3749 kg, with an operating capacity of approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
60 hp
Max power
37.4 kW
Weight
3749 kg
Catalogue coverage
Variants represented
2
Richest spec table
31 rows
Recorded power
60 hp
Recorded weight
3749 kg
Transmissions
16-speed
Production years
2005-2007
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerMcCormick IntlReference
Built in Doncaster, EnglandReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (optional)Reference
Engine
Perkins 4.2L 4-cyl dieselReference
Engine54.4 kWReference
Drawbar (tested)37.4 kWReference
PerkinsReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.2 LReference
Power54.4 kWReference
Air cleanertwo paper elementsReference
Power at rated engine speed44.5 kWReference
Max power37.4 kWReference
Transmission
16-speedReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
PTO (claimed)43.3 kWReference
PTO (tested)44.5 kWReference
Power at rated PTO speed46.3 kWReference
Dimensions
Weight3749 kgReference
Operating weight3749 kgReference
Test results
Diesel 16-speed 4WDLink: OCED Tractor Test 1895 fileReference
PTO performanceReference
Fuel use14.8 l/hourReference
Drawbar performanceReference
Fuel use15.1 l/hourReference
Gear 6 used for power test.Reference
Max pull4302 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
