Tractor · 2004Unverified

McCormick Intl C85 Max High Clear

Name: McCormick Intl C85 Max High Clear
Brand: McCormick Intl

McCormick Intl C85 Max High Clear — C-Max Series · 73 hp. Reference specifications; pending source verification.

The McCormick Intl C85 Max High Clear is a tractor model with a rated output of 73 hp, positioning it in the middle of its class for power. Produced from 2004 to 2007, the C85 Max High Clear is powered by a 4-cylinder diesel liquid-cooled engine, which drives through a mechanical front-wheel drive system with a hydrostatic transmission. The tractor's listed weight is 8048 to 8533 pounds. It is designed for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

73 hp

Weight

8048 to 8533 pounds

Catalogue coverage

Variants represented

Richest spec table

61 rows

Recorded power

73 hp

Recorded weight

3650 kg

Transmissions

12-speed synchronized shuttle

Production years

2004-2007

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMcCormick Intl (a part of Argo)Reference

High-Clearance tractorReference

Drive4x2 2WDReference

Drive4x4 MFWD 4WD (optional)Reference

Steeringhydrostatic powerReference

ROPS. Cab optional.Reference

Variants

C85 MaxutilityReference

C85HChigh-cropReference

Engine

Perkins 4.4L 4-cyl dieselReference

Engine61.1 kWReference

PerkinsReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.4 LReference

Bore/Stroke105 x 127 mmReference

Power61.1 kWReference

Rated RPM2200Reference

Torque292.9 NmReference

Transmission

12-speed synchronized shuttleReference

24-speed synchronized shuttle with creeperReference

24-speed synchronized shuttle with overdriveReference

Typesynchronized shuttleReference

Gears12 forward and reverseReference

Typesynchronized shuttle with creeperReference

Gears24 forward and 12 reverseReference

Typesynchronized shuttle with overdriveReference

PTO & Hydraulics

PTO (claimed)54.4 kWReference

Hydraulic system34.4 LReference

Hydraulic system37.1 LReference

Typeopen centerReference

Capacity34.4 LReference

Capacity37.1 LReference

Valves1 or 2Reference

Pump flow52.2 lpmReference

Rear TypeIIReference

Rear lift (at ends)2600 kgReference

Rear lift (at ends)3700 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Capacities

Fuel102.2 LReference

Dimensions

Wheelbase265 cmReference

Wheelbase264 cmReference

Weight8048 to 8533 poundsReference

Front tire7.5-20Reference

Rear tire13.6R38Reference

Ag front7.5-20 (2WD)Reference

Ag front13.6R38 (4WD)Reference

Ag front9.5R48 (4WD)Reference

Ag rear13.6R38Reference

Ag rear7.5R48Reference

Length419 cmReference

Width208 cmReference

Width220 cmReference

Weight3650 kgReference

Weight3870 kgReference

Ground clearance62 cmReference

Ground clearance74 cmReference

Ground clearance68 cmReference

Electrical

Charging systemalternatorReference

Charging amps55Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
