Tractor · 2007Unverified
McCormick Intl CT47
McCormick Intl CT47 — CT Series · 47 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
47 hp
Weight
1625 kg
Hover a source tag to verify
Overview
DistributorMcCormick Intl (a part of Argo)Reference
ManufacturerLSReference
Compact Utility tractorReference
Original price was $30,600 in 2008Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Mitsubishi 2.5L 4-cyl dieselReference
Fuel tank37.9 LReference
Engine (gross)35.0 kWReference
Mitsubishi S4QLReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke89 x 104 mmReference
Power (gross)35.0 kWReference
Pre-heatingglow plugsReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed synchro shuttleReference
hydrostaticReference
32-speed shuttle with creeperReference
Typesynchro shuttleReference
Gears16 forward and reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
Typeshuttle with creeperReference
Gears32 forward and 16 reverseReference
PTO & Hydraulics
Gear PTO (claimed)30.6 kWReference
Hydro PTO (claimed)29.1 kWReference
Valves2Reference
Pump flow31.0 lpmReference
Gear Steering flow15.5 lpmReference
Hydro Steering flow20.8 lpmReference
Rear TypeIReference
Rear lift (at ends)1250 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Mid PTO Type2100Reference
Dimensions
Wheelbase175 cmReference
Weight1625 kgReference
Front tire9.5-16Reference
Rear tire12.4-24Reference
Weight226 kgReference
Weight396 kgReference
Ag front9.5-16Reference
Ag rear12.4-24Reference
Length320 cmReference
Width170 cmReference
Height (ROPS)249 cmReference
Ground clearance35 cmReference
Front tread131 cmReference
Rear tread130 cmReference
McCormick Intl CT47 attachments
72" mid-mount mower deckReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Charging volts12Reference
Battery volts12Reference
Attachment overview
72" mid-mount mower deckReference
Front-end loaderReference
BackhoeReference
72" Mower deck
Typemid-mount McCormick MS72Reference
Cutting width182 cmReference
Cut height2 to 10 cmReference
McCormick Intl MH76 Backhoe
Backhoe typeMcCormick Intl MH76 BackhoeReference
Bucket width22 cmReference
Bucket width33 cmReference
Bucket width40 cmReference
Bucket width50 cmReference
Bucket width60 cmReference
Digging depth243 cmReference
2-Foot flat digging depth228 cmReference
Reach from pivot289 cmReference
Loading height177 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1288 kgReference
Dipperstick force909 kgReference
McCormick Intl MH86 Backhoe
Backhoe typeMcCormick Intl MH86 BackhoeReference
Transport height205 cmReference
Bucket width35 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
Bucket width91 cmReference
Bucket width101 cmReference
Digging depth274 cmReference
2-Foot flat digging depth259 cmReference
Reach from pivot337 cmReference
Loading height208 cmReference
Bucket force1691 kgReference
Dipperstick force1104 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
