Tractor · 2009Unverified

McCormick Intl CTJ23

Name: McCormick Intl CTJ23
Brand: McCormick Intl

McCormick Intl CTJ23 — CTJ Series · 19 hp. Reference specifications; pending source verification.

The McCormick Intl CTJ23 tractor has an engine rating of approximately 19 hp, positioning it at the lower end of its class. Production of the CTJ23 model spanned from 2009 to 2014. It features a 3-cylinder diesel liquid-cooled engine, coupled with a four-wheel drive system and a hydrostatic transmission. The tractor's operating weight is listed at 729 kg, and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

19 hp

Weight

729 kg

Catalogue coverage

Variants represented

Richest spec table

59 rows

Recorded power

19 hp

Recorded weight

729 kg

Transmissions

hydrostatic

Production years

2009-2014

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMcCormick IntlReference

Compact Utility tractorReference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Mitsubishi 1.1L 3-cyl dieselReference

Fuel tank25.0 LReference

Engine17.2 kWReference

Mitsubishi S3LReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.1 LReference

Bore/Stroke78 x 92 mmReference

EmissionsTier IIIReference

Power17.2 kWReference

Air cleanerdryReference

Pre-heatingglow plugReference

Rated RPM2700Reference

StarterelectricReference

Starter volts12Reference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

PTO & Hydraulics

PTO (claimed)13.8 kWReference

Typeopen centerReference

Valves1Reference

Pump flow17.0 lpmReference

Total flow26.9 lpmReference

Steering flow9.8 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at ends)650 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Mid PTOindependentReference

Mid PTO Type2000Reference

Dimensions

Wheelbase152 cmReference

Weight729 kgReference

Weight185 kgReference

Industrial front23x8.50-12Reference

Industrial rear12x16.5Reference

Length261 cmReference

Width116 cmReference

Height (ROPS)215 cmReference

Height (Folded ROPS)175 cmReference

Ground clearance25 cmReference

McCormick Intl CTJ23 attachments

60" mid-mount mower deckReference

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps50Reference

Battery volts12Reference

Attachment overview

60" mid-mount mower deckReference

Front-end loaderReference

60" Mower deck

Typemid-mount McCormick MS60Reference

Cutting width152 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
