Tractor · 2000Unverified

McCormick Intl CX60

Name: McCormick Intl CX60
Brand: McCormick Intl

McCormick Intl CX60 — CX Series · 64 hp. Reference specifications; pending source verification.

The McCormick Intl CX60 is a tractor with a rated power output of 64 hp, positioning it at the lower end of its class. Manufactured from 2000 to 2004, this model features a 3-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive and a powershift transmission. The tractor's listed operating weight falls within the range of 7132 to 7815 pounds, and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

64 hp

Weight

7132 to 7815 pounds

Catalogue coverage

Variants represented

Richest spec table

51 rows

Recorded power

64 hp

Recorded weight

3235 kg

Transmissions

8-speed synch shuttle

Production years

2000-2004

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMcCormick Intl (a part of Argo)Reference

Utility tractorReference

Built in Doncaster, EnglandReference

Two- or four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Cab standard.Reference

Engine

Perkins 2.7L 3-cyl dieselReference

Fuel tank155.2 LReference

Engine47.7 kWReference

PerkinsReference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.7 LReference

Bore/Stroke95 x 127 mmReference

Power47.7 kWReference

Rated RPM2250Reference

Torque222.0 NmReference

Torque RPM1400Reference

StarterelectricReference

Starter volts12Reference

Transmission

8-speed synch shuttleReference

16-speed two-speed power shiftReference

Typesynch shuttleReference

Gears8 forward and reverseReference

Clutch304mm dry discReference

Typetwo-speed power shiftReference

Gears16 forward and 8 reverseReference

PTO & Hydraulics

Typeopen centerReference

SCV flow53.0 lpmReference

Rear TypeIIReference

Rear lift2039 kgReference

Rear PTOindependentReference

Clutchhydraulic wet discReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@1954Reference

Dimensions

2WD Wheelbase215 cmReference

4WD Wheelbase221 cmReference

Weight7132 to 7815 poundsReference

Front tire7.50-16Reference

2WD Rear tire13.6R36Reference

2WD Standard tires (ag)Front: 7.50-16. Rear: 13.6R36Reference

4WD Standard tires (ag)Front: 11.2R24. Rear: 13.6R36Reference

Length406 cmReference

Width196 cmReference

Width214 cmReference

2WD Weight3235 kgReference

4WD Weight3544 kgReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
