Tractor · 2003Unverified
McCormick Intl CX75
McCormick Intl CX75 — CX Series · 73 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
73 hp
Max power
37.4 kW
Weight
3770 kg
Hover a source tag to verify
Overview
ManufacturerMcCormick IntlReference
Utility tractorReference
Built in Doncaster, EnglandReference
Two- or four-wheel driveReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
ROPS. Cab optional.Reference
Engine
Perkins 4.2L 4-cyl dieselReference
Perkins 4.4L 4-cyl dieselReference
Engine (net)54.4 kWReference
Engine54.4 kWReference
Drawbar (tested)37.4 kWReference
Perkins 1004.4Reference
dieselReference
4-cylinderReference
liquid-cooledReference
The Tier I engine was used from the start of the CX 05 series in 2003 until spring of 2004.Reference
Displacement4.2 LReference
Bore/Stroke103 x 127 mmReference
EmissionsTier IReference
Rated Power (net)54.4 kWReference
Air cleanerdual paper elementsReference
Compression18.5:1Reference
Rated RPM2200Reference
Torque271.1 NmReference
Starter volts12Reference
Perkins 1104Reference
liquid-cooled inlineReference
The Tier II Perkins 1104 was introduced in 2004 with the same horsepower rating as the original engine.Reference
Displacement4.4 LReference
Bore/Stroke105 x 127 mmReference
EmissionsTier IIReference
Power54.4 kWReference
Power at rated engine speed44.5 kWReference
Max power37.4 kWReference
Transmission
24-speed partial power shiftReference
8-speed synchro shuttleReference
16-speed partial power shiftReference
TransmissionXtrashiftReference
Typepartial power shiftReference
Gears24 forward and reverseReference
Clutchwet discReference
Eight gears with a three-range power shift for each gear. Optional creeper provides 36 gears forward and reverse.Reference
Typesynchro shuttleReference
Gears8 forward and reverseReference
Clutchdry discReference
Gears16 forward and 8 reverseReference
Four gears in two ranges with two-speed power shift. Optional creeper provides 24-forward and 12-reverse.Reference
PTO & Hydraulics
PTO (claimed)44.7 kWReference
PTO (tested)44.5 kWReference
Hydraulic system34.4 LReference
Hydraulic system36.7 LReference
Typeopen centerReference
Capacity34.4 LReference
Capacity36.7 LReference
Pump flow60.0 lpmReference
Rear lift2040 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@2000Reference
Engine RPM1000@2000Reference
Power at rated PTO speed46.3 kWReference
Capacities
Fuel155.2 LReference
Dimensions
Wheelbase235 cmReference
Weight3770 kgReference
Front tire7.50-16Reference
Rear tire16.9R34Reference
Ag front7.50-16Reference
Ag front11.2R24 (4WD)Reference
Ag rear16.9R34Reference
Length421 cmReference
Height254 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps65Reference
Battery volts12Reference
Test results
4.2L diesel 16-speed 4WDOctober 1998 - November 1998, Link: OCED Tractor Test 1895 fileReference
PTO performanceReference
Fuel use14.8 l/hourReference
Drawbar performanceReference
Fuel use15.1 l/hourReference
Gear 3L-DD used for power test.Reference
Max pull4302 kgReference
Gear 1L-TA used for pull test.Reference
Speeds
With 18.4-34 rear tires.Reference
With 16.9R34 rear tires.Reference
