Tractor · 2008Unverified

McCormick Intl CX90

Name: McCormick Intl CX90
Brand: McCormick Intl

McCormick Intl CX90 — CX Series · 66 hp. Reference specifications; pending source verification.

The McCormick Intl CX90 is a tractor with a rated power output of 66 hp, positioned within the mid-range of its class. This model was manufactured from 2008 to 2011. Key features of the McCormick Intl CX90 include a 4-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive and a powershift transmission. It is designed for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

66 hp

Weight

8311.4 to 8465.7 pounds

Catalogue coverage

Variants represented

Richest spec table

64 rows

Recorded power

66 hp

Recorded weight

3840 kg

Transmissions

24-speed power shuttle

Production years

2008-2011

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMcCormick IntlReference

Utility tractorReference

Built in ItalyReference

Four-wheel driveReference

SteeringpowerReference

Wet disc brakesReference

Cab standard. Optional sir-conditioning.Reference

Engine

Perkins 4.4L 4-cyl dieselReference

Fuel tank154.8 LReference

Engine61.9 kWReference

Perkins 1104D-44TReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.4 LReference

Bore/Stroke105 x 127 mmReference

EmissionsTier 3Reference

Power61.9 kWReference

StarterelectricReference

Starter volts12Reference

Transmission

24-speed power shuttleReference

36-speed power shuttleReference

8-speed 16Reference

TransmissionXtrashiftReference

Typepower shuttleReference

Gears24 forward and reverseReference

Three power shift speeds in each of four gears. High and low ranges.Reference

Gears36 forward and reverseReference

Three power shift speeds in each of four gears. High, low, and creeper ranges.Reference

Transmissionsynchronized shuttleReference

Type16Reference

Gears8 forwardReference

PTO & Hydraulics

PTO (claimed)49.2 kWReference

Valves2Reference

Pump flow59.8 lpmReference

Total flow89.7 lpmReference

Steering flow29.9 lpmReference

Rear TypeIIReference

Rear lift2957 kgReference

Rear lift4099 kgReference

Front HitchIIReference

Front lift3000 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Rear PTO Type540/750Reference

Front PTOindependentReference

Front PTO Type1000Reference

Dimensions

Wheelbase235 cmReference

Weight8311.4 to 8465.7 poundsReference

Front tire320/85R24Reference

Rear tire420/85R34Reference

Ag front320/85R24Reference

Ag rear420/85R34Reference

Length422 cmReference

Width234 cmReference

Width196 cmReference

Height (cab)273 cmReference

Height (cab)254 cmReference

Weight3840 kgReference

Weight3770 kgReference

Ground clearance41 cmReference

CX90 Serial Numbers

Location:Serial number plate on the right side of the radiator support bracket, under the hood.Reference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
