Tractor · 2003Unverified

McCormick Intl CX95

McCormick Intl CX95 — CX Series · 90 hp. Reference specifications; pending source verification.

The McCormick Intl CX95 is a tractor rated at approximately 90 hp, a mid-range figure for its class. It was produced from 2003 to 2007. The CX95 features a 4-cylinder turbocharged diesel liquid-cooled engine paired with four-wheel drive and a hydrostatic transmission. Its operating weight ranges from 8312 to 8467 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
90 hp
Weight
8312 to 8467 pounds

Catalogue coverage

Variants represented
2
Richest spec table
72 rows
Recorded power
90 hp
Recorded weight
3770 kg
Transmissions
24-speed partial power shift
Production years
2003-2007
Verified variants
0

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMcCormick IntlReference
Utility tractorReference
Built in Doncaster, EnglandReference
Two- or four-wheel driveReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
ROPS. Cab optional.Reference

Engine

Perkins 4.0L 4-cyl dieselReference
Perkins 4.4L 4-cyl dieselReference
Engine (net)67.1 kWReference
Engine67.1 kWReference
PerkinsReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
The Tier I engine was used from the start of the CX 05 series in 2003 until spring of 2004.Reference
Displacement4.0 LReference
Bore/Stroke100 x 127 mmReference
EmissionsTier IReference
Rated Power (net)67.1 kWReference
Rated RPM2200Reference
Torque355.0 NmReference
Starter volts12Reference
Perkins 1104Reference
liquid-cooled inlineReference
The Tier II Perkins 1104 was introduced in 2004 with the same horsepower rating as the original engine.Reference
Displacement4.4 LReference
Bore/Stroke105 x 127 mmReference
EmissionsTier IIReference
Power67.1 kWReference

Transmission

24-speed partial power shiftReference
8-speed synchro shuttleReference
16-speed partial power shiftReference
TransmissionXtrashiftReference
Typepartial power shiftReference
Gears24 forward and reverseReference
Clutchwet discReference
Eight gears with a three-range power shift for each gear. Optional creeper provides 36 gears forward and reverse.Reference
Typesynchro shuttleReference
Gears8 forward and reverseReference
Clutchdry discReference
Gears16 forward and 8 reverseReference
Four gears in two ranges with two-speed power shift.Reference

PTO & Hydraulics

PTO (claimed)55.2 kWReference
Hydraulic system34.4 LReference
Hydraulic system36.7 LReference
Typeopen centerReference
Capacity34.4 LReference
Capacity36.7 LReference
Pump flow60.0 lpmReference
Rear lift3875 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@2000Reference
Engine RPM1000@2000Reference

Capacities

Fuel155.2 LReference

Dimensions

Wheelbase235 cmReference
Weight8312 to 8467 poundsReference
Front tire10.00-16Reference
Rear tire16.9R34Reference
Ag front10.00-16Reference
Ag front12.4R24 (4WD)Reference
Ag rear16.9R34Reference
Length421 cmReference
Height274 cmReference
2WD Weight3770 kgReference
4WD Weight3840 kgReference

Electrical

GroundnegativeReference
Charging systemalternatorReference
Charging amps65Reference
Battery volts12Reference

Speeds

With 18.4-34 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
