McCormick Intl F105
McCormick Intl F105 — F Series · 91 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
91 hp
Weight
5766 to 6714 pounds
Hover a source tag to verify
Overview
ManufacturerMcCormick Intl (a part of Argo)Reference
Orchard/Vineyard tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post mid-mount folding ROPS. Cab optional with optional air conditioning.Reference
Variants
F105standard narrowReference
F105XLwide deluxeReference
Engine
Perkins 4.4L 4-cyl dieselReference
F/GE Fuel tank48.1 LReference
F/GE Fuel tank73.1 LReference
XL Fuel tank65.1 LReference
XL Fuel tank90.1 LReference
Engine73.1 kWReference
Perkins 1104C-44TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke105 x 127 mmReference
EmissionsTier IIReference
Power73.1 kWReference
Fuel systemdirect injectionReference
Rated RPM2200Reference
Torque380.1 NmReference
StarterelectricReference
Starter volts12Reference
Transmission
15-speed mechanical shuttleReference
15-speed power shuttleReference
30-speed two-speed power shiftReference
Typemechanical shuttleReference
Gears15 forward and reverseReference
Clutch304mm mechanical dry discReference
Five gears in three ranges with mechanical shuttle. Also available with creeper range, providing 20 speeds.Reference
Typepower shuttleReference
Clutchwet discReference
Five gears in three ranges with power shuttle. Also available with creeper range, providing 20 speeds.Reference
Typetwo-speed power shiftReference
Gears30 forward and reverseReference
Five gears in three ranges with power shuttle and two-speed power shift in each gear. Also available with creeper range, providing 40 speeds.Reference
PTO & Hydraulics
PTO (claimed)67.9 kWReference
Typeopen centerReference
F/GE Valves2Reference
XL Valves3Reference
Pump flow52.2 lpmReference
Total flow82.1 lpmReference
Steering flow29.9 lpmReference
Rear TypeIIReference
Rear lift2600 kgReference
Rear PTOindependentReference
Clutchdry discReference
Clutchwet discReference
Rear PTO Type540/750Reference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase213 cmReference
Weight5766 to 6714 poundsReference
Front tire280/70R20Reference
Rear tire14.9R28Reference
Ag front280/70R20Reference
Ag rear14.9R28Reference
Length370 cmReference
Width124 cmReference
Height (ROPS)228 cmReference
Height (Folded ROPS)139 cmReference
Height (cab)220 cmReference
Ground clearance35 cmReference
2WD ROPS2615 kgReference
4WD ROPS2845 kgReference
2WD Cab2815 kgReference
4WD Cab3045 kgReference
Electrical
Charging systemalternatorReference
Charging amps85Reference
Speeds
With 16.9R24 rear tires. Reverse speeds are 1% faster than forward.Reference
With 14.9R28 rear tires. Reverse speeds are 3% slower than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
