Tractor · 2002Unverified
McCormick Intl F60
McCormick Intl F60 — Model year 2002-20032004-2008 · 55 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
55 hp
Hover a source tag to verify
Overview
ManufacturerMcCormick Intl (a part of Argo)Reference
Orchard/Vineyard tractorReference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Differential lockelectro-hydraulic rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post ROPS. Cab optional with air-conditioning.Reference
Engine
Perkins 2.7L 3-cyl dieselReference
Fuel tank53.0 LReference
XL Fuel tank62.1 LReference
Engine41.0 kWReference
PerkinsReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke95 x 127 mmReference
Power41.0 kWReference
Air cleanerdual dry elementReference
Rated RPM2300Reference
Torque193.1 NmReference
Torque RPM1200Reference
StarterelectricReference
Starter volts12Reference
Oil change250 hReference
Transmission
12-speed sync shuttleReference
24-speedReference
Typesync shuttleReference
Gears12 forward and reverseReference
Clutch279.4mm organic dry discReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
Typeopen centerReference
Pressure180.0 barReference
Valves2Reference
Valves3 (XL version)Reference
Pump flow44.3 lpmReference
Pump flow46.9 lpmReference
Steering flow17.4 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift2600 kgReference
Rear PTOindependentReference
Rear PTO Type540/540E/750 (1.375)Reference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@1944Reference
Engine RPM750@1375Reference
Engine RPM1000@1916Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
