Tractor · 2004Unverified

McCormick Intl F95

Name: McCormick Intl F95
Brand: McCormick Intl

McCormick Intl F95 — F Series · 85 hp. Reference specifications; pending source verification.

The McCormick Intl F95 is a mid-range tractor model with an approximate engine rating of 85 horsepower. Manufactured between 2004 and 2008, it features a 4-cylinder turbocharged diesel liquid-cooled engine, coupled with four-wheel drive and a powershift transmission. The operating weight of the McCormick Intl F95 ranges from 5766 to 6714 pounds. This model is designed for use in operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

85 hp

Weight

5766 to 6714 pounds

Catalogue coverage

Variants represented

Richest spec table

76 rows

Recorded power

85 hp

Transmissions

15-speed mechanical shuttle

Production years

2004-2008

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMcCormick Intl (a part of Argo)Reference

Orchard/Vineyard tractorReference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post mid-mount folding ROPS. Cab optional.Reference

Variants

F95standard narrowReference

F95XLwide deluxeReference

Engine

Perkins 4.4L 4-cyl dieselReference

F/GE Fuel tank48.1 LReference

F/GE Fuel tank73.1 LReference

XL Fuel tank65.1 LReference

XL Fuel tank90.1 LReference

Engine70.8 kWReference

Perkins 1104C-44TReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.4 LReference

Bore/Stroke105 x 127 mmReference

EmissionsTier IIReference

Power70.8 kWReference

Fuel systemdirect injectionReference

Rated RPM2200Reference

Torque364.1 NmReference

StarterelectricReference

Starter volts12Reference

Transmission

15-speed mechanical shuttleReference

15-speed power shuttleReference

30-speed two-speed power shiftReference

Typemechanical shuttleReference

Gears15 forward and reverseReference

Clutch304mm mechanical dry discReference

Five gears in three ranges with mechanical shuttle. Also available with creeper range, providing 20 speeds.Reference

Typepower shuttleReference

Clutchwet discReference

Five gears in three ranges with power shuttle. Also available with creeper range, providing 20 speeds.Reference

Typetwo-speed power shiftReference

Gears30 forward and reverseReference

Five gears in three ranges with power shuttle and two-speed power shift in each gear. Also available with creeper range, providing 40 speeds.Reference

PTO & Hydraulics

PTO (claimed)63.4 kWReference

Typeopen centerReference

F/GE Valves2Reference

XL Valves3Reference

Pump flow52.2 lpmReference

Total flow82.1 lpmReference

Steering flow29.9 lpmReference

Rear TypeIIReference

Rear lift2600 kgReference

Rear PTOindependentReference

Clutchdry discReference

Clutchwet discReference

Rear PTO Type540/750Reference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase217 cmReference

Wheelbase213 cmReference

Weight5766 to 6714 poundsReference

Front tire7.50-16Reference

Rear tire14.9R28Reference

Ag front7.50-16 (2WD)Reference

Ag front280/70R20 (4WD)Reference

Ag rear14.9R28Reference

Length370 cmReference

Width124 cmReference

Height (ROPS)228 cmReference

Height (Folded ROPS)139 cmReference

Height (cab)220 cmReference

Ground clearance35 cmReference

2WD ROPS2615 kgReference

4WD ROPS2845 kgReference

2WD Cab2815 kgReference

4WD Cab3045 kgReference

Electrical

Charging systemalternatorReference

Charging amps85Reference

Speeds

With 16.9R24 rear tires. Reverse speeds are 1% faster than forward.Reference

With 14.9R28 rear tires. Reverse speeds are 3% slower than forward.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
