Tractor · 2011Unverified

McCormick Intl G125 Max

McCormick Intl G125 Max — G Max Series · 100 hp. Reference specifications; pending source verification.

The McCormick Intl G125 Max is a mid-range tractor with an approximate power output of 100 hp. It was manufactured from 2011 to 2015. The tractor is equipped with a 6-cylinder turbocharged intercooled diesel liquid-cooled engine, paired with a four-wheel drive system and hydrostatic transmission. Its operating weight is listed at 5787 kg, suitable for operations spanning 200 to 800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
100 hp
Weight
5787 kg

Catalogue coverage

Variants represented
2
Richest spec table
48 rows
Recorded power
100 hp
Recorded weight
5787 kg
Transmissions
36-speed mechanical shuttle
Production years
2011-2015
Verified variants
0

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMcCormick Intl (a part of Argo)Reference
Row-Crop tractorReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Trailer brakeshydraulic (optional)Reference
Two-post ROPS. Cab optional with air-conditioning.Reference

Engine

BetaPower 6.7L 6-cyl dieselReference
Fuel tank260.0 LReference
BetaPowerReference
turbocharged air-to-air intercooled dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.7 LReference
Bore/Stroke104 x 132 mmReference
EmissionsTier 3Reference
Maximum Power87.2 kWReference
Compression17.5:1Reference
Rated RPM2200Reference
Torque515.3 NmReference
Torque RPM1250Reference
StarterelectricReference
Starter volts12Reference

Transmission

36-speed mechanical shuttleReference
Typemechanical shuttleReference
Gears36 forward and reverseReference
Clutch355mm dry discReference

PTO & Hydraulics

PTO (claimed)74.6 kWReference
Valves3 to 5Reference
Pump flow68.1 lpmReference
Total flow106.0 lpmReference
Rear TypeIII/IIReference
Controlposition controlReference
Rear lift6985 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference

Dimensions

Wheelbase279 cmReference
Weight5787 kgReference
Front tire380/70R28Reference
Rear tire480/70R38Reference
Standard tires (ag)Front: 380/70R28. Rear: 480/70R38Reference
Length514 cmReference
Width205 cmReference
Height (ROPS)276 cmReference
Ground clearance52 cmReference
Rear tread158 to 209 cmReference

Electrical

GroundnegativeReference
Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
