Tractor · 2002Unverified

McCormick Intl GX45

Name: McCormick Intl GX45
Brand: McCormick Intl

McCormick Intl GX45 — GX Series · 44 hp. Reference specifications; pending source verification.

The McCormick Intl GX45 is a tractor model with a rated power output of approximately 44 hp, positioning it at the lighter end of its class. Initially produced from 2002 to 2007, the GX45 features a 4-cylinder diesel liquid-cooled engine coupled with four-wheel drive and a hydrostatic transmission. Its operating weight ranges from 3197 to 3483 pounds, and it is suitable for operations of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

44 hp

Weight

3197 to 3483 pounds

Catalogue coverage

Variants represented

Richest spec table

83 rows

Recorded power

44 hp

Transmissions

hydrostatic

Production years

2002-2007

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMcCormick Intl (a part of Argo)Reference

Compact Utility tractorReference

Two- or four-wheel driveReference

Differential lockelectro-hydraulic front and rearReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Two-post foldable ROPS. Cab optional with air-conditioning.Reference

Variants

GX45Hhydrostatic transmissionReference

Engine

Yanmar 2.0L 4-cyl dieselReference

Fuel tank50.0 LReference

Engine (gross)32.8 kWReference

Engine (net)29.8 kWReference

YanmarReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.0 LReference

Bore/Stroke84 x 90 mmReference

Power (net)29.8 kWReference

Power (gross)32.8 kWReference

Fuel systemdirect injectionReference

Air cleanerdry elementReference

Compression18:1Reference

Rated RPM2800Reference

Torque120.0 NmReference

Torque RPM1600Reference

Starter volts12Reference

Transmission

hydrostaticReference

12-speed synchronized shuttleReference

16-speed synchronized shuttle with creeperReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

Typesynchronized shuttleReference

Gears12 forward and reverseReference

Clutch225mm mechanical dry discReference

Typesynchronized shuttle with creeperReference

Gears16 forward and reverseReference

PTO & Hydraulics

Typeopen centerReference

Valves2 or 3Reference

Pump flow28.0 lpmReference

Total flow39.0 lpmReference

Steering flow11.0 lpmReference

Rear TypeIReference

Controlposition and draft controlReference

Rear lift1200 kgReference

Front HitchINReference

Front lift400 kgReference

Rear PTOliveReference

Shuttle Clutchmechanical dry discReference

Hydro Clutchelectro-hydraulic wet discReference

Rear PTO Type540/750 (1.375)Reference

Mid PTOoptionalReference

Mid PTO Type1000Reference

Front PTOoptionalReference

Front PTO Type1000 (1.375)Reference

Dimensions

2WD Wheelbase180 cmReference

4WD Wheelbase182 cmReference

Weight3197 to 3483 poundsReference

Front tire280/70R16Reference

Rear tire340/65R28Reference

Standard tires (ag)Front: 280/70R16. Rear: 340/65R28Reference

Optional tires (ag)Front: 270/70R16. Rear: 340/65R28 (4WD)Reference

Optional tires (ag)Front: 200/70R16. Rear: 320/70R20 (4WD)Reference

Optional tires (ag)Front: 280/70R16. Rear: 360/70R24 (4WD)Reference

Optional tires (ag)Front: 27x8.50-16. Rear: 38x14-20 (4WD)Reference

Optional tires (ag)Front: 8.00-12. Rear: 360/70R20 (2WD)Reference

Optional tires (ag)Front: 5.00-15. Rear: 320/70R20 (2WD)Reference

Optional tires (ag)Front: 7.50-10. Rear: 320/70R20 (2WD)Reference

Optional tires (ag)Front: 6.50-16. Rear: 360/70R24 (2WD)Reference

Length342 cmReference

Width137 cmReference

Height (steering wheel)145 cmReference

Height (ROPS)233 cmReference

Ground clearance37 cmReference

Front tread110 to 135 cmReference

Rear tread110 to 126 cmReference

2WD Shuttle1450 kgReference

4WD Shuttle1529 kgReference

2WD Hydro1500 kgReference

4WD Hydro1579 kgReference

McCormick Intl GX45 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
