Tractor · 2006Unverified
McCormick Intl MB65
McCormick Intl MB65 — MB Series · 62 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
62 hp
Weight
5285 to 6090 pounds
Hover a source tag to verify
Overview
ManufacturerMcCormick IntlReference
Utility tractorReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (optional)Reference
Steeringhydrostatic powerReference
Mechanical wet disc brakesReference
Four-post ROPS. Optional canopy.Reference
Engine
Perkins 4.4L 4-cyl dieselReference
Fuel tank87.1 LReference
Engine50.0 kWReference
Perkins 1104C-44Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke105 x 127 mmReference
Power50.0 kWReference
Compression19.3:1Reference
Rated RPM2200Reference
Torque272.6 NmReference
Torque RPM1400Reference
Transmission
12-speedReference
24-speedReference
Gears12 forward and reverseReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
PTO (claimed)46.2 kWReference
Pressure179.3 barReference
Valves1 or 2Reference
Pump flow52.2 lpmReference
Total flow76.5 lpmReference
Rear TypeIIReference
Rear lift2585 kgReference
Rear lift3692 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
Wheelbase224 cmReference
Wheelbase222 cmReference
Weight5285 to 6090 poundsReference
Front tire7.50-16Reference
Rear tire16.9R30Reference
Ag front7.50-16 (2WD)Reference
Ag front11.2R24 (4WD)Reference
Ag rear16.9R30Reference
Length342 cmReference
Width182 cmReference
Height (steering wheel)169 cmReference
Height (ROPS)254 cmReference
Weight2397 kgReference
Weight2762 kgReference
Ground clearance36 cmReference
Front tread132 to 181 cmReference
Front tread141 to 195 cmReference
Rear tread150 to 190 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
