Tractor · 2006Unverified

McCormick Intl MB65

Name: McCormick Intl MB65
Brand: McCormick Intl

McCormick Intl MB65 — MB Series · 62 hp. Reference specifications; pending source verification.

The McCormick Intl MB65 is a tractor model with a rated power of 62 hp, positioning it in the lower power range of its class. It was manufactured from 2006 to 2010. The tractor features a 4-cylinder diesel liquid-cooled engine, paired with a mechanical front-wheel drive system and a hydrostatic transmission. It has an operating weight of 5285 to 6090 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

62 hp

Weight

5285 to 6090 pounds

Catalogue coverage

Variants represented

Richest spec table

53 rows

Recorded power

62 hp

Recorded weight

2397 kg

Transmissions

12-speed

Production years

2006-2010

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMcCormick IntlReference

Utility tractorReference

Drive4x2 2WDReference

Drive4x4 MFWD 4WD (optional)Reference

Steeringhydrostatic powerReference

Mechanical wet disc brakesReference

Four-post ROPS. Optional canopy.Reference

Engine

Perkins 4.4L 4-cyl dieselReference

Fuel tank87.1 LReference

Engine50.0 kWReference

Perkins 1104C-44Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.4 LReference

Bore/Stroke105 x 127 mmReference

Power50.0 kWReference

Compression19.3:1Reference

Rated RPM2200Reference

Torque272.6 NmReference

Torque RPM1400Reference

Transmission

12-speedReference

24-speedReference

Gears12 forward and reverseReference

Gears24 forward and 12 reverseReference

PTO & Hydraulics

PTO (claimed)46.2 kWReference

Pressure179.3 barReference

Valves1 or 2Reference

Pump flow52.2 lpmReference

Total flow76.5 lpmReference

Rear TypeIIReference

Rear lift2585 kgReference

Rear lift3692 kgReference

Rear PTOindependentReference

Rear PTO Type540Reference

Dimensions

Wheelbase224 cmReference

Wheelbase222 cmReference

Weight5285 to 6090 poundsReference

Front tire7.50-16Reference

Rear tire16.9R30Reference

Ag front7.50-16 (2WD)Reference

Ag front11.2R24 (4WD)Reference

Ag rear16.9R30Reference

Length342 cmReference

Width182 cmReference

Height (steering wheel)169 cmReference

Height (ROPS)254 cmReference

Weight2397 kgReference

Weight2762 kgReference

Ground clearance36 cmReference

Front tread132 to 181 cmReference

Front tread141 to 195 cmReference

Rear tread150 to 190 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
