Tractor · 2008Unverified
McCormick Intl MC110
McCormick Intl MC110 — MC Series · 83 hp. Reference specifications; pending source verification.
The McCormick Intl MC110 is a tractor model specified with an 83 hp rated power, a mid-range figure for its class. Manufactured from 2008 to 2013, this model is powered by a 4-cylinder turbocharged diesel liquid-cooled engine and features a four-wheel drive system with a powershift transmission. Its operating weight is listed as 4844 kg, and it is suitable for operations of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
83 hp
Weight
4844 kg
Catalogue coverage
Variants represented
2
Richest spec table
49 rows
Recorded power
83 hp
Recorded weight
4844 kg
Transmissions
16-speed four-speed power shift
Production years
2008-2013
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerMcCormick Intl (a part of Argo)Reference
Utility tractorReference
Built in ItalyReference
Four-wheel driveReference
Final driveselectro-hydraulic rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Perkins 4.4L 4-cyl dieselReference
Fuel tank196.1 LReference
Engine75.0 kWReference
Perkins 1104D-44TAReference
turbocharged aftercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke105 x 127 mmReference
EmissionsTier 3Reference
Power75.0 kWReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed four-speed power shiftReference
Typefour-speed power shiftReference
Gears16 forward and 12 reverseReference
Four power shift gears in four ranges with power shuttle. Optional AutoSpeed offers push-button shifting and programmable gear selection.Reference
PTO & Hydraulics
PTO (claimed)61.5 kWReference
Typeclosed centerReference
Valves2 or 3Reference
Pump flow109.0 lpmReference
Rear TypeIIINReference
Rear lift5870 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase251 cmReference
Weight4844 kgReference
Front tire380/85R28Reference
Rear tire460/85R38Reference
Standard tires (ag)Front: 380/85R28. Rear: 460/85R38Reference
Length442 cmReference
Width230 cmReference
Height (cab)278 cmReference
Height (cab)259 cmReference
Shipping weight4844 kgReference
Clearance (drawbar)38 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
