Tractor · 2000Unverified
McCormick Intl MC115
McCormick Intl MC115 — Model year 2000-20032003-20072008-2013 · 96 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
96 hp
Weight
5495 kg
Hover a source tag to verify
Overview
ManufacturerMcCormick IntlReference
Utility tractorReference
Built in Doncaster, EnglandReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Perkins 4.4L 4-cyl dieselReference
Engine85.8 kWReference
Perkins 1104C-44TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke105 x 127 mmReference
EmissionsTier 2Reference
Power85.8 kWReference
Rated RPM2200Reference
Torque480.0 NmReference
Torque RPM1300Reference
Starter volts12Reference
Oil change500 hReference
Transmission
16-speed four-speed power shiftReference
32-speed creeperReference
Typefour-speed power shiftReference
Gears16 forward and 12 reverseReference
Four ranges with four power shift gears in each range.Reference
TypecreeperReference
Gears32 forward and 24 reverseReference
PTO & Hydraulics
PTO (claimed)71.6 kWReference
Hydraulic system74.9 LReference
Typeload-sensingReference
Capacity74.9 LReference
Valves2 to 4Reference
Pump flow109.0 lpmReference
Rear TypeIINReference
Rear lift (at 24"/610mm)3719 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2163Reference
Engine RPM1000@2200Reference
Capacities
Fuel196.1 LReference
Dimensions
Wheelbase251 cmReference
Weight5495 kgReference
Front tire14.9-28Reference
Rear tire18.4-38Reference
Standard tires (ag)Front: 14.9-28. Rear: 18.4-38Reference
Length441 cmReference
Width195 cmReference
Height280 cmReference
Clearance (drawbar)40 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps95Reference
Battery volts12Reference
Speeds
With 18.4-38 rear tires and 40KPH transmission option.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
