Tractor · 2000Unverified

McCormick Intl MTX110

Name: McCormick Intl MTX110
Brand: McCormick Intl

McCormick Intl MTX110 — MTX Series · 102 hp. Reference specifications; pending source verification.

The McCormick Intl MTX110 is a tractor with an approximate engine rating of 102 horsepower, placing it within a mid-range bracket for its class. The MTX110 model was manufactured between 2000 and 2003. It features a 6-cylinder turbocharged diesel liquid-cooled engine, coupled with four-wheel drive and a powershift transmission. The tractor's operating weight is listed as 11900 to 13420 pounds, making it suitable for operations spanning 200 to 800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

102 hp

Max power

76.5 kW

Weight

11900 to 13420 pounds

Catalogue coverage

Variants represented

Richest spec table

77 rows

Recorded power

102 hp

Transmissions

16-speed four-speed power shift

Production years

2000-2003

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMcCormick Intl (a part of Argo)Reference

Row-Crop tractorReference

Built in Doncaster, EnglandReference

Four-wheel driveReference

Differential lockelectro-hydraulic rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Cab standard with air-conditioning.Reference

Engine

Perkins 6.0L 6-cyl dieselReference

Fuel tank264.9 LReference

Engine86.5 kWReference

Drawbar (claimed)65.6 kWReference

Drawbar (tested)65.6 kWReference

Perkins 1006-60TReference

turbocharged dieselReference

6-cylinderReference

liquid-cooled inlineReference

Displacement6.0 LReference

Bore/Stroke100 x 127 mmReference

Power86.5 kWReference

Air cleanerdual paper elementsReference

Compression17.2:1Reference

Rated RPM2200Reference

Torque465.1 NmReference

Torque RPM1400Reference

StarterelectricReference

Starter volts12Reference

Oil change300 hReference

Max power76.5 kWReference

Power at rated engine speed75.9 kWReference

Max power65.6 kWReference

Transmission

16-speed four-speed power shiftReference

32-speed creeperReference

Typefour-speed power shiftReference

Gears16 forward and 12 reverseReference

Clutchelectro-hydraulic wet discReference

Four power shift gears in four ranges.Reference

TypecreeperReference

Gears32 forward and 24 reverseReference

PTO & Hydraulics

PTO (claimed)76.1 kWReference

PTO (tested)76.5 kWReference

Typepressure flow compensatingReference

Pump flow109.0 lpmReference

SCV flow95.0 lpmReference

Rear TypeIIReference

Controlelectronic lower link draft sensingReference

Rear lift (at 24"/610mm)3719 kgReference

Rear lift (at 24"/610mm)4617 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM540@1877Reference

Engine RPM1000@2200Reference

Dimensions

Wheelbase270 cmReference

Weight11900 to 13420 poundsReference

Front tire14.9R28Reference

Rear tire18.4R38Reference

Ag front14.9R28Reference

Ag rear18.4R38Reference

Length516 cmReference

Width230 cmReference

Height (cab)288 cmReference

6087 kgReference

Shipping5397 kgReference

Max front axle6100 kgReference

Max rear axle9498 kgReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps95Reference

Battery volts12Reference

Test results

Diesel 16-speed 4WD5/2002Link: OCED Tractor Test 2097 fileReference

PTO performanceReference

Fuel use25.0 l/hourReference

Fuel use25.7 l/hourReference

Drawbar performanceReference

Fuel use25.4 l/hourReference

Max pull6556 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
