Tractor · 2004Unverified
McCormick Intl MTX165
McCormick Intl MTX165 — MTX Series · 159 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
159 hp
Max power
132.7 kW
Weight
7341 kg
Hover a source tag to verify
Overview
ManufacturerMcCormick IntlReference
Row-Crop tractorReference
Built in Doncaster, EnglandReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Differential hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Iveco 6.8L 6-cyl dieselReference
Fuel tank347.1 LReference
Engine119.3 kWReference
Drawbar (tested)105.2 kWReference
IvecoReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.8 LReference
Bore/Stroke104 x 132 mmReference
Power119.3 kWReference
Rated RPM2200Reference
Torque654.1 NmReference
Torque RPM1600Reference
Starter volts12Reference
Max power132.7 kWReference
Power at rated engine speed118.8 kWReference
Max power105.2 kWReference
Transmission
16-speedReference
32-speedReference
TransmissionpowershiftReference
Gears16 forward and 12 reverseReference
Gears32 forward and 24 reverseReference
PTO & Hydraulics
PTO (claimed)105.1 kWReference
PTO (tested)132.7 kWReference
Typepressure flow compensatingReference
Pump flow121.1 lpmReference
Rear TypeIIIReference
Controlelectronic lower link draft sensingReference
Rear lift8328 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540/1000Reference
Power at rated PTO speed129.9 kWReference
Dimensions
Wheelbase286 cmReference
Weight7341 kgReference
Front tire480/70R30Reference
Rear tire20.8R42Reference
Ag front480/70R30Reference
Ag rear20.8R42Reference
Length523 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps95Reference
Charging amps120Reference
Battery volts12Reference
Test results
Diesel 32/24 4WDMay 11 - 16, 2006Link: OCED Tractor Test 1880 fileReference
PTO performanceReference
Fuel use36.7 l/hourReference
Fuel use36.0 l/hourReference
Fuel use37.1 l/hourReference
Drawbar performanceReference
Gear 3-2 used for power test.Reference
Max pull7069 kgReference
Gear 1-7 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
