Tractor · 2003Unverified

McCormick Intl MTX200

Name: McCormick Intl MTX200
Brand: McCormick Intl

McCormick Intl MTX200 — MTX Series · 170 hp. Reference specifications; pending source verification.

The McCormick Intl MTX200 is a tractor rated at 170 hp, categorising it among the more powerful machines in its class. Manufactured between 2003 and 2005, the MTX200 is equipped with a 6-cylinder turbocharged diesel liquid-cooled engine, which drives a four-wheel drive system via a hydrostatic transmission. The stated weight of the tractor is 7711 kg. It is designed for land areas of approximately 600–1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

170 hp

Weight

7711 kg

Catalogue coverage

Variants represented

Richest spec table

47 rows

Recorded power

170 hp

Recorded weight

7711 kg

Transmissions

16-speed

Production years

2003-2005

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMcCormick IntlReference

Row-Crop tractorReference

Built in Doncaster, EnglandReference

Four-wheel driveReference

Steeringhydrostatic powerReference

Differential hydraulic wet disc brakesReference

Cab standard with air-conditioning.Reference

Engine

Cummins 5.9L 6-cyl dieselReference

Fuel tank347.1 LReference

Engine152.1 kWReference

Cummins QSBReference

turbocharged dieselReference

6-cylinder 24-valveReference

liquid-cooledReference

Displacement5.9 LReference

Bore/Stroke102 x 120 mmReference

Power152.1 kWReference

Rated RPM2200Reference

Torque800.0 NmReference

Torque RPM1200Reference

Starter volts12Reference

Transmission

16-speedReference

32-speedReference

TransmissionpowershiftReference

Gears16 forward and 12 reverseReference

Gears32 forward and 24 reverseReference

PTO & Hydraulics

PTO (claimed)126.8 kWReference

Typepressure flow compensatingReference

Pump flow121.1 lpmReference

Rear TypeIIIReference

Controlelectronic lower link draft sensingReference

Rear lift10951 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase286 cmReference

Weight7711 kgReference

Front tire640/65R30Reference

Rear tire650/65R42Reference

Ag front640/65R30Reference

Ag rear650/65R42Reference

Length523 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps95Reference

Charging amps120 (optional)Reference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
