Tractor · 2009Unverified
McCormick Intl T90
McCormick Intl T90 — T Crawler Series · 77 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
77 hp
Weight
5130 kg
Hover a source tag to verify
Overview
ManufacturerMcCormick Intl (a part of Argo)Reference
Agricultural Crawler tractorReference
DrivecrawlerReference
Steeringhydrostatic wet clutchesReference
Two-post ROPS.Reference
Engine
Perkins 4.4L 4-cyl dieselReference
Fuel tank95.0 LReference
Engine67.9 kWReference
Perkins 1104D-44TReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke105 x 127 mmReference
EmissionsTier IIIReference
Power67.9 kWReference
Compression18.2:1Reference
Rated RPM2200Reference
Torque352.0 NmReference
Torque RPM1400Reference
Transmission
16-speedReference
Gears16 forward and 8 reverseReference
Clutchcerametallic dry discReference
PTO & Hydraulics
PTO (claimed)57.4 kWReference
Typeopen centerReference
Pressure180.0 barReference
Valves4 to 6Reference
Pump flow38.6 lpmReference
Total flow65.5 lpmReference
Steering flow26.9 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift2649 kgReference
Rear lift3400 kgReference
Rear PTOindependentReference
Rear PTO Type540/750Reference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase165 cmReference
Weight5130 kgReference
15.8-inch tracksReference
Length350 cmReference
Width169 cmReference
Height (hood)129 cmReference
Height (ROPS)230 cmReference
Ground clearance32 cmReference
Gauge130 cmReference
McCormick Intl T90 Tracks
Width40 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
