The McCormick Intl VF90 is a tractor rated at 91 hp — putting it around the middle of its class for power. Power comes from a 4-cylinder diesel engine, driving through a 12-speed gearbox. It is aimed at jobs of around 200–800 ac. Available dimensions and performance figures follow in both unit systems.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
91 hp
Catalogue coverage
Variants represented
2
Richest spec table
21 rows
Recorded power
91 hp
Transmissions
12-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerMcCormick IntlReference
Engine
4.0L 4-cyl dieselReference
Fuel tank0.0 LReference
Engine67.9 kWReference
dieselReference
4-cylinderReference
Displacement4.0 LReference
Bore/Stroke100 x 127 mmReference
Power67.9 kWReference
Rated RPM2200Reference
Torque358.1 NmReference
Torque RPM1400Reference
Transmission
12-speedReference
24-speedReference
Gears12 forward and reverseReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
Pump flow42.4 lpmReference
Rear TypeI,IIReference
Rear lift2600 kgReference
Rear PTO Type540, 750 (1000 optional)Reference
Electrical
Charging amps55Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
