Tractor · 2011Unverified
McCormick Intl X10.40H
McCormick Intl X10.40H — X10 Series · 41 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
41 hp
Weight
3950 to 4299 pounds
Hover a source tag to verify
Overview
DistributorMcCormick IntlReference
ManufacturerDaedongReference
Compact Utility tractorReference
Built in South KoreaReference
Four-wheel driveReference
Differential lockrear standardReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post foldable ROPS. Cab optional with air-conditioning and CD player.Reference
Variants
X10.40MgearReference
X10.40HhydrostaticReference
Engine
Daedong 2.0L 4-cyl dieselReference
Fuel tank45.0 LReference
Engine (gross)30.6 kWReference
Daedong 4A200Reference
dieselReference
4-cylinderReference
liquid-cooled vertical inlineReference
Displacement2.0 LReference
Power (gross)30.6 kWReference
Fuel systemindirect injectionReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
PTO (claimed)24.2 kWReference
Typegear pumpReference
Valves1 or 2Reference
Pump flow63.6 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at 24"/610mm)1130 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Dimensions
Wheelbase187 cmReference
Weight3950 to 4299 poundsReference
Front tire8-16Reference
Rear tire13.6-24Reference
Ag front8-16Reference
Ag rear13.6-24Reference
Lawn/turf front29x12.5-15Reference
Lawn/turf rear21.5L-16.1Reference
Industrial front10x16.5Reference
Industrial rear14.9x24Reference
Length340 cmReference
Width162 cmReference
Height (ROPS)241 cmReference
Weight1791 kgReference
Weight1950 kgReference
Ground clearance37 cmReference
Front tread124 cmReference
Rear tread126 to 148 cmReference
McCormick Intl X10.40H attachments
front-end loaderReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
