Tractor · 2011Unverified

McCormick Intl X10.40H

Name: McCormick Intl X10.40H
Brand: McCormick Intl

McCormick Intl X10.40H — X10 Series · 41 hp. Reference specifications; pending source verification.

The McCormick Intl X10.40H is a compact tractor with a rated power output of 41 hp. Manufactured from 2011 to 2014, it features a 4-cylinder diesel liquid-cooled engine, powering four-wheel drive through a hydrostatic transmission. The tractor's weight ranges from 3950 to 4299 pounds. It is designed to perform tasks on land areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

41 hp

Weight

3950 to 4299 pounds

Catalogue coverage

Variants represented

Richest spec table

59 rows

Recorded power

41 hp

Recorded weight

1791 kg

Transmissions

hydrostatic

Production years

2011-2014

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorMcCormick IntlReference

ManufacturerDaedongReference

Compact Utility tractorReference

Built in South KoreaReference

Four-wheel driveReference

Differential lockrear standardReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Two-post foldable ROPS. Cab optional with air-conditioning and CD player.Reference

Variants

X10.40MgearReference

X10.40HhydrostaticReference

Engine

Daedong 2.0L 4-cyl dieselReference

Fuel tank45.0 LReference

Engine (gross)30.6 kWReference

Daedong 4A200Reference

dieselReference

4-cylinderReference

liquid-cooled vertical inlineReference

Displacement2.0 LReference

Power (gross)30.6 kWReference

Fuel systemindirect injectionReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverseReference

PTO & Hydraulics

PTO (claimed)24.2 kWReference

Typegear pumpReference

Valves1 or 2Reference

Pump flow63.6 lpmReference

Rear TypeIReference

Controlposition and draft controlReference

Rear lift (at 24"/610mm)1130 kgReference

Rear PTOindependentReference

Rear PTO Type540Reference

Mid PTOoptionalReference

Mid PTO Type2000Reference

Dimensions

Wheelbase187 cmReference

Weight3950 to 4299 poundsReference

Front tire8-16Reference

Rear tire13.6-24Reference

Ag front8-16Reference

Ag rear13.6-24Reference

Lawn/turf front29x12.5-15Reference

Lawn/turf rear21.5L-16.1Reference

Industrial front10x16.5Reference

Industrial rear14.9x24Reference

Length340 cmReference

Width162 cmReference

Height (ROPS)241 cmReference

Weight1791 kgReference

Weight1950 kgReference

Ground clearance37 cmReference

Front tread124 cmReference

Rear tread126 to 148 cmReference

McCormick Intl X10.40H attachments

front-end loaderReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
