Tractor · 2011Unverified
McCormick Intl X10.50M
McCormick Intl X10.50M — X10 Series · 49 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
49 hp
Weight
1799 kg
Hover a source tag to verify
Overview
DistributorMcCormick IntlReference
ManufacturerDaedongReference
Compact Utility tractorReference
Built in South KoreaReference
Four-wheel driveReference
Differential lockrear standardReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post ROPS.Reference
Variants
X10.50HhydrostaticReference
X10.50MgearReference
Engine
Daedong 2.4L dieselReference
Fuel tank45.0 LReference
Engine (gross)36.5 kWReference
Daedong 4B243Reference
dieselReference
liquid-cooledReference
Displacement2.4 LReference
Power (gross)36.5 kWReference
Fuel systemindirect injectionReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed synchronized shuttleReference
Typesynchronized shuttleReference
Gears12 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)31.1 kWReference
Typegear pumpReference
Valves1 or 2Reference
Pump flow63.6 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at 24"/610mm)1130 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Dimensions
Wheelbase187 cmReference
Weight1799 kgReference
Front tire8-16Reference
Rear tire13.6-24Reference
Ag front8-16Reference
Ag rear13.6-24Reference
Lawn/turf front29x12.5-15Reference
Lawn/turf rear21.5L-16.1Reference
Industrial front10x16.5Reference
Industrial rear14.9x24Reference
Length340 cmReference
Width162 cmReference
Height (ROPS)244 cmReference
Ground clearance37 cmReference
Front tread124 cmReference
Rear tread126 to 148 cmReference
McCormick Intl X10.50M attachments
front-end loaderReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
