Tractor · 2011Unverified
McCormick Intl X10.55M
McCormick Intl X10.55M — X10 Series · 54 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
54 hp
Weight
4795 to 5180 pounds
Hover a source tag to verify
Overview
DistributorMcCormick IntlReference
ManufacturerDaedongReference
Compact Utility tractorReference
Built in South KoreaReference
Four-wheel driveReference
Differential lockrear standardReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post ROPS. Cab optional with air-conditioning and CD-player.Reference
Engine
Daedong 2.2L dieselReference
Fuel tank68.1 LReference
Engine (gross)40.3 kWReference
Daedong 4A220TLWBReference
turbocharged dieselReference
liquid-cooled vertical inlineReference
Displacement2.2 LReference
Power (gross)40.3 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed synchronized shuttleReference
Typesynchronized shuttleReference
Gears12 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)33.7 kWReference
Typegear pumpReference
Valves2Reference
Total flow53.8 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at 24"/610mm)1203 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase192 cmReference
Weight4795 to 5180 poundsReference
Front tire9.5x20Reference
Rear tire14.9x28Reference
Ag front9.5x20Reference
Ag rear14.9x28Reference
Lawn/turf front29x12.5-15Reference
Lawn/turf rear44x18-20Reference
Industrial front14x17.5Reference
Industrial rear18.4x24Reference
Length331 cmReference
Width176 cmReference
Height (ROPS)270 cmReference
Height (cab)252 cmReference
Weight2175 kgReference
Weight2349 kgReference
Ground clearance44 cmReference
Front tread146 cmReference
Rear tread136 cmReference
McCormick Intl X10.55M attachments
front-end loaderReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
