Tractor · 2011Unverified

McCormick Intl X10.55M

Name: McCormick Intl X10.55M
Brand: McCormick Intl

McCormick Intl X10.55M — X10 Series · 54 hp. Reference specifications; pending source verification.

The McCormick Intl X10.55M is a tractor with a rated power output of 54 hp, positioning it at the lighter end of its class. The X10.55M model was manufactured from 2011 to 2014. It features a turbocharged diesel liquid-cooled engine paired with four-wheel drive and a hydrostatic transmission. The tractor's operating weight ranges from 4795 to 5180 pounds, suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

54 hp

Weight

4795 to 5180 pounds

Catalogue coverage

Variants represented

Richest spec table

55 rows

Recorded power

54 hp

Recorded weight

2175 kg

Transmissions

12-speed synchronized shuttle

Production years

2011-2014

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorMcCormick IntlReference

ManufacturerDaedongReference

Compact Utility tractorReference

Built in South KoreaReference

Four-wheel driveReference

Differential lockrear standardReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Two-post ROPS. Cab optional with air-conditioning and CD-player.Reference

Engine

Daedong 2.2L dieselReference

Fuel tank68.1 LReference

Engine (gross)40.3 kWReference

Daedong 4A220TLWBReference

turbocharged dieselReference

liquid-cooled vertical inlineReference

Displacement2.2 LReference

Power (gross)40.3 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed synchronized shuttleReference

Typesynchronized shuttleReference

Gears12 forward and reverseReference

Clutchdry discReference

PTO & Hydraulics

PTO (claimed)33.7 kWReference

Typegear pumpReference

Valves2Reference

Total flow53.8 lpmReference

Rear TypeIReference

Controlposition and draft controlReference

Rear lift (at 24"/610mm)1203 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase192 cmReference

Weight4795 to 5180 poundsReference

Front tire9.5x20Reference

Rear tire14.9x28Reference

Ag front9.5x20Reference

Ag rear14.9x28Reference

Lawn/turf front29x12.5-15Reference

Lawn/turf rear44x18-20Reference

Industrial front14x17.5Reference

Industrial rear18.4x24Reference

Length331 cmReference

Width176 cmReference

Height (ROPS)270 cmReference

Height (cab)252 cmReference

Weight2175 kgReference

Weight2349 kgReference

Ground clearance44 cmReference

Front tread146 cmReference

Rear tread136 cmReference

McCormick Intl X10.55M attachments

front-end loaderReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
