Tractor · 2011Unverified
McCormick Intl X10.90M
McCormick Intl X10.90M — X10 Series · 91 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
91 hp
Weight
4039 kg
Hover a source tag to verify
Overview
DistributorMcCormick IntlReference
ManufacturerDaedongReference
Utility tractorReference
Built in South KoreaReference
Four-wheel driveReference
Differential lockrear standardReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Cab standard with air-condioning, CD player, and rear wiper.Reference
Engine
Perkins 4.4L 4-cyl dieselReference
Fuel tank124.9 LReference
Engine (gross)68.0 kWReference
Perkins D1104D-44TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Power (gross)68.0 kWReference
Fuel systemindirect injectionReference
Pre-heatingglow plugsReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed syncronized shuttleReference
Typesyncronized shuttleReference
Gears16 forward and reverseReference
Clutchdry discReference
Four gears in four ranges with synchronized shuttle.Reference
PTO & Hydraulics
PTO (claimed)58.2 kWReference
Valves2 or 3Reference
Total flow83.6 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift (at 24"/610mm)2399 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase230 cmReference
Weight4039 kgReference
Front tire12.4x24Reference
Rear tire18.4x34Reference
Standard tires (ag)Front: 12.4x24. Rear: 18.4x34Reference
Length411 cmReference
Width197 cmReference
Height (cab)275 cmReference
Ground clearance42 cmReference
Front tread151 to 171 cmReference
Rear tread156 to 196 cmReference
McCormick Intl X10.90M attachments
front-end loaderReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
