Tractor · 2015Unverified
McCormick Intl X1.25
McCormick Intl X1.25 — X1 Series · 21 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
21 hp
Weight
821 kg
Hover a source tag to verify
Overview
DistributorMcCormick Intl (a part of Argo)Reference
ManufacturerKukjeReference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Variants
X1.25gearReference
X1.25HhydrostaticReference
Engine
Kukje 1.2L 3-cyl dieselReference
Fuel tank23.6 LReference
Engine17.9 kWReference
KukjeReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.2 LReference
EmissionsTier IVReference
Power17.9 kWReference
Fuel systemmechanical indirect injectionReference
Air cleanerdual element dryReference
Pre-heatingglow plugsReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed gearReference
hydrostaticReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
Gear PTO (claimed)15.7 kWReference
Hydro PTO (claimed)13.4 kWReference
Typeopen centerReference
Rear valves1Reference
Pump flow18.2 lpmReference
Steering flow12.9 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)680 kgReference
Rear PTOliveReference
Rear PTO Type540Reference
Mid PTO Type2500Reference
Dimensions
Wheelbase152 cmReference
Weight821 kgReference
Length269 cmReference
Height (ROPS)223 cmReference
McCormick Intl X1.25 attachments
60" mid-mount mower deckReference
front-end loaderReference
X1.25 Serial Number Location
Serial number plate on the right side of the tractor frame, above the front axle.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
Front-end loaderReference
60" Mower deck
Typemid-mount McCormick Intl BM60Reference
Type3-bladeReference
Cutting width152 cmReference
Cut height2 to 8 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
