Tractor · 2012Unverified

McCormick Intl X50.30

Name: McCormick Intl X50.30
Brand: McCormick Intl

McCormick Intl X50.30 — X50 Series · 82 hp. Reference specifications; pending source verification.

The McCormick Intl X50.30 is a mid-range tractor, rated at approximately 82 horsepower. It was manufactured between 2012 and 2014. The tractor features a 4-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive and a hydrostatic transmission. Its operating weight ranges from 8030 to 8470 pounds, and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

82 hp

Weight

8030 to 8470 pounds

Catalogue coverage

Variants represented

Richest spec table

68 rows

Recorded power

82 hp

Recorded weight

3642 kg

Transmissions

12-speed mechanical shuttle

Production years

2012-2014

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMcCormick Intl (a part of Argo)Reference

Utility tractorReference

Two- or four-wheel driveReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Two-post foldable ROPS. Cab available with air-conditioning.Reference

Engine

Perkins 3.4L 4-cyl dieselReference

Fuel tank102.2 LReference

Perkins 854E-E34TAReference

turbocharged aftercooled dieselReference

4-cylinder 8-valveReference

liquid-cooledReference

Displacement3.4 LReference

Bore/Stroke99 x 110 mmReference

EmissionsInterim Tier 4Reference

Emission controlexhaust gas recirculation (EGR)Reference

Maximum Power70.8 kWReference

Maximum Power76.1 kWReference

Fuel systemdirect injectionReference

Air cleanerdryReference

Compression17:1Reference

Rated RPM2200Reference

Torque RPM1400Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed mechanical shuttleReference

12-speed power shutteReference

32-speed three-speed power shift with power shuttleReference

TransmissionSpeed FourReference

Typemechanical shuttleReference

Gears12 forward and reverseReference

Clutch330mm dry discReference

Typepower shutteReference

Clutchwet discsReference

TransmissionXtraspeedReference

Typethree-speed power shift with power shuttleReference

Gears32 forward and 12 reverseReference

PTO & Hydraulics

PTO (claimed)60.8 kWReference

PTO (claimed)64.5 kWReference

Valves2 to 4Reference

Pump flow52.2 lpmReference

Total flow81.8 lpmReference

Rear TypeIIReference

Controlposition and draft controlReference

Rear lift4740 kgReference

Front HitchoptionalReference

Front lift1796 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulic wet discsReference

Rear PTO Type540/750Reference

Rear PTO Type540/1000Reference

Rear PTO Type540/750/1000Reference

Front PTOindependent (optional)Reference

Dimensions

2WD Wheelbase236 cmReference

4WD Wheelbase233 cmReference

Weight8030 to 8470 poundsReference

Front tire380/70R24Reference

Rear tire480/70R34Reference

Standard tires (ag)Front: 380/70R24. Rear: 480/70R34Reference

Length416 cmReference

Width210 cmReference

Height (ROPS)255 cmReference

Height (cab)256 cmReference

Weight3642 kgReference

Weight3841 kgReference

Ground clearance46 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
