Tractor · 2014Unverified
McCormick Intl X6.480
McCormick Intl X6.480 — X6 Series · 170 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
170 hp
Weight
5987 kg
Hover a source tag to verify
Overview
ManufacturerMcCormick Intl (a part of Argo)Reference
Four-wheel driveReference
Differential lockelectro-hydraulicReference
Wet disc brakesReference
Trailer brakeshydraulicReference
Trailer brakespneumaticReference
Cab standard with air-conditioning. Optional pneumatic seat suspension.Reference
Engine
BetaPower 4.5L 4-cyl dieselReference
Fuel tank269.9 LReference
Exhaust fluid (DEF)37.9 LReference
Engine (gross)126.8 kWReference
Engine (max)131.2 kWReference
BetaPowerReference
dieselReference
4-cylinder 16-valveReference
liquid-cooledReference
Displacement4.5 LReference
Bore/Stroke104 x 132 mmReference
EmissionsInterim Tier IVReference
Emission controlselective catalytic reduction (SCR)Reference
Rated Power (gross)126.8 kWReference
Maximum Power (gross)131.2 kWReference
Rated RPM2200Reference
Torque680.0 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
18-speedReference
54-speedReference
Gears18 forward and reverseReference
Clutchdry discReference
TransmissionT-TronicReference
Gears54 forward and 18 reverseReference
PTO & Hydraulics
Valves3 to 5Reference
Pump flow87.1 lpmReference
Rear TypeIII/IIReference
Controlposition and draft controlReference
Rear lift8382 kgReference
Front HitchIIReference
Front lift3492 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/1000Reference
Front PTOindependentReference
Front PTO Type1000Reference
Dimensions
Wheelbase271 cmReference
Weight5987 kgReference
Front tire480/65R28Reference
Rear tire650/65R38Reference
Ag front480/65R28Reference
Ag rear650/65R38Reference
Length525 cmReference
Width220 cmReference
Height (cab)279 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
