Tractor · 2005Unverified
McCormick Intl XTX200
McCormick Intl XTX200 — XTX Series · 171 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
171 hp
Max power
143.4 kW
Weight
15880 to 16010 pounds
Hover a source tag to verify
Overview
ManufacturerMcCormick Intl (a part of Argo)Reference
Row-Crop tractorReference
Built in Doncaster, EnglandReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Iveco 6.7L 6-cyl dieselReference
Fuel tank347.1 LReference
Engine146.0 kWReference
Drawbar (tested)104.7 kWReference
IvecoReference
turbocharged dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement6.7 LReference
Bore/Stroke104 x 132 mmReference
Power146.0 kWReference
Air cleanerdual paper elementsReference
Compression17.5:1Reference
Rated RPM2200Reference
Torque800.2 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Max power143.4 kWReference
Power at rated engine speed127.5 kWReference
Max power104.7 kWReference
Transmission
32-speed 8-speed power shiftReference
48-speedReference
TransmissionXtraSpeedReference
Type8-speed power shiftReference
Gears32 forward and 24 reverseReference
Four ranges with eight power shift gears in each range. Power shuttle. XtraSpeed-E option provides push-button range shifting.Reference
TransmissionXtraSpeed CreeperReference
Gears48 forward and 40 reverseReference
PTO & Hydraulics
PTO (tested)143.4 kWReference
Typeclosed centerReference
Total flow129.1 lpmReference
Total flow163.1 lpmReference
Rear TypeIIIReference
Rear lift10951 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Rear PTO Type540E/1000Reference
Power at rated PTO speed136.3 kWReference
Dimensions
Wheelbase287 cmReference
Weight15880 to 16010 poundsReference
Front tire540/65R30Reference
Rear tire650/65R42Reference
Ag front540/65R30Reference
Ag rear650/65R42Reference
Length530 cmReference
Height302 cmReference
Weight7262 kgReference
Shipping weight7203 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps120Reference
Battery volts12Reference
Test results
Diesel 32-speed 4WDMay 17 - June 7, 2006Link: OCED Tractor Test 1881 fileReference
PTO performanceReference
Fuel use39.7 l/hourReference
Fuel use38.6 l/hourReference
Fuel use39.0 l/hourReference
Drawbar performanceReference
Fuel use36.0 l/hourReference
Gear 3-2 used for power test.Reference
Max pull7084 kgReference
Gear 2-3 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
