The McCulloch D-20 is a tractor with a rating of approximately 20 hp, positioning it at the lighter end of its class. Production of this model took place from 1965 to 1970. It features a 2-cylinder diesel liquid-cooled engine, coupled with two-wheel drive and a 6-speed gearbox. The tractor is suited for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Catalogue coverage
Variants represented
2
Richest spec table
22 rows
Recorded power
20 hp
Transmissions
6-speed gear
Production years
1965-1970
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorMcCullochReference
ManufacturerKubotaReference
Compact Utility tractorReference
Built in JapanReference
The McCulloch-Kubota D-20 was imported into the United States in the late 1960s, prior to Kubota's entry to the market.Reference
Two-wheel driveReference
Open operator station.Reference
Engine
Kubota 2-cyl dieselReference
Engine14.9 kWReference
KubotaReference
dieselReference
2-cylinderReference
liquid-cooledReference
Power14.9 kWReference
Starter volts12Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Three-speed transmission with high and low ranges.Reference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Links
D20: short article on the D20 at Gas Engine MagazineReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
