The McKee 460 is a tractor rated at 57 hp — making it one of the more compact options in its class. It is powered by a 4-cylinder diesel liquid-cooled engine, driving through two-wheel drive with a 8-speed gearbox. Listed weight is 2039 kg, and it is aimed at jobs of around up to 200 ac. Recorded specifications in UK and US units are listed below.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
57 hp
Weight
2039 kg
Catalogue coverage
Variants represented
2
Richest spec table
44 rows
Recorded power
57 hp
Recorded weight
2039 kg
Transmissions
8-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerMcKeeReference
Utility tractorReference
Built in SpainReference
Two-wheel driveReference
Open operator station.Reference
Engine
Perkins 3.3L 4-cyl dieselReference
Fuel tank65.1 LReference
Engine45.6 kWReference
Perkins AD4.203Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke91 x 127 mmReference
Power45.6 kWReference
Compression18.5:1Reference
Rated RPM2250Reference
Torque218.7 NmReference
Torque RPM1250Reference
Starter volts12Reference
Oil capacity7.0 LReference
Coolant capacity11.0 LReference
Transmission
8-speedReference
Gears8 forward and 2 reverseReference
Oil capacity26.5 LReference
PTO & Hydraulics
PTO (claimed)42.5 kWReference
Rear TypeIIReference
Rear PTO540 (1.375)Reference
Rear PTO Type540:2250Reference
Dimensions
Wheelbase201 cmReference
Weight2039 kgReference
Front tire7.00x16Reference
Rear tire12x36Reference
Ag front7.00x16Reference
Ag rear12x36Reference
Ag front6.00x16Reference
Ag front6.00x19Reference
Ag front6.50x16Reference
Ag rear14x30Reference
Ag rear14x38Reference
Length337 cmReference
Height (steering wheel)155 cmReference
Ballasted weight3460 kgReference
Ground clearance48 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
