Tractor · 1987Unverified
Memo M100
Memo M100 — Row-Crop tractor · 102 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
102 hp
Weight
6497 kg
Hover a source tag to verify
Overview
ManufacturerMemoReference
Row-Crop tractorReference
Built in YugoslaviaReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic disc brakesReference
Cab standard.Reference
Engine
Deutz 5.7L 6-cyl dieselReference
Engine76.1 kWReference
Deutz F6L912Reference
dieselReference
6-cylinderReference
air-cooledReference
Displacement5.7 LReference
Bore/Stroke99 x 119 mmReference
Power76.1 kWReference
Rated RPM2400Reference
StarterelectricReference
Starter volts12Reference
Starter power4.0 kWReference
Transmission
20-speedReference
Gears20 forward and 5 reverseReference
Clutchdry discReference
PTO & Hydraulics
Typeopen centerReference
Pressure172.4 barReference
Valves2Reference
Rear TypeIIIReference
Rear lift5080 kgReference
Rear PTOliveReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Weight6497 kgReference
Front tire11.2x28Reference
Rear tire18.4x34Reference
Ag front11.2x28Reference
Ag rear18.4x34Reference
Length444 cmReference
Width228 cmReference
Electrical
Charging systemalternatorReference
Charging amps28Reference
Battery volts12Reference
Battery AH110Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
