Tractor · 1987Unverified
Memo M451
Memo M451 — Utility tractor · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
3499 kg
Hover a source tag to verify
Overview
ManufacturerMemoReference
Utility tractorReference
Built in YugoslaviaReference
Two-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Mechanical drum brakesReference
Open operator station. Cab available.Reference
Engine
Deutz 2.8L 3-cyl dieselReference
Engine33.6 kWReference
Deutz F3L912Reference
dieselReference
3-cylinderReference
air-cooledReference
Displacement2.8 LReference
Bore/Stroke99 x 119 mmReference
Power33.6 kWReference
Compression17:1Reference
Rated RPM2300Reference
Torque164.8 NmReference
Torque RPM1500Reference
Starter volts12Reference
Starter power3.0 kWReference
Oil capacity9.0 LReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
Clutchdry discReference
Oil capacity13.9 LReference
Capacities
Fuel70.0 LReference
PTO & Hydraulics
Hydraulic system9.8 LReference
Typeopen centerReference
Capacity9.8 LReference
Pressure172.4 barReference
Valvesup to 3Reference
Pump flow36.8 lpmReference
Rear TypeIReference
Rear lift1632 kgReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2077Reference
Dimensions
Wheelbase199 cmReference
Weight3499 kgReference
Front tire7.5x16Reference
Rear tire14.9x28Reference
Ag front7.5x16Reference
Ag rear14.9x28Reference
Length346 cmReference
Width176 cmReference
Height (steering wheel)177 cmReference
Clearance (front axle)45 cmReference
Clearance (rear axle)54 cmReference
Front tread132 to 182 cmReference
Rear tread127 to 171 cmReference
Electrical
Charging systemalternatorReference
Charging amps28Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
