Tractor · 1987Unverified
Memo M752
Memo M752 — M75 Series · 73 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
73 hp
Hover a source tag to verify
Overview
ManufacturerMemoReference
Utility tractorReference
Built in YugoslaviaReference
Drive4x2 2WDReference
Drive4x4 4WDReference
Differential lockmechanical rearReference
Power steeringReference
Mechanical drum brakesReference
Trailer brakespneumaticReference
Cab standard.Reference
Variants
M7522WDReference
M752A4WDReference
Engine
Torpedo-Deutz 3.8L 4-cyl dieselReference
Engine54.4 kWReference
Torpedo-Deutz F4L912Reference
dieselReference
4-cylinderReference
air-cooledReference
Displacement3.8 LReference
Bore/Stroke100 x 120 mmReference
Power54.4 kWReference
Rated RPM2300Reference
Torque219.9 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed gearReference
TransmissionTW56.10Reference
TypegearReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
Typeopen centerReference
Pressure172.4 barReference
Pump flow43.5 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift3402 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2025Reference
Engine RPM1000@2166Reference
Dimensions
Wheelbase241 cmReference
Front tire7.5x16Reference
2WD Rear tire18.4x30Reference
2WD Standard tires (ag)Front: 7.5x16. Rear: 18.4x30Reference
4WD Standard tires (ag)Front: 11.2x24. Rear: 18.4x30Reference
Length400 cmReference
Width207 cmReference
Height (steering wheel)182 cmReference
Ballasted weight4998 kgReference
Clearance (front axle)56 cmReference
Clearance (rear axle)62 cmReference
Front tread142 to 202 cmReference
Rear tread151/161/172/182/201 cmReference
Electrical
Charging systemalternatorReference
Charging amps28Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
