Tractor · 1982Unverified
Mercedes-Benz Trac 1000
Mercedes-Benz Trac 1000 — Four-wheel Drive (4WD) tractor · 100 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
100 hp
Weight
4500 kg
Hover a source tag to verify
Overview
ManufacturerMercedes-BenzReference
Four-wheel Drive (4WD) tractorReference
Drive4x4 4WDReference
Steeringhydrostatic powerReference
Engine
Mercedes-Benz 5.7L 6-cyl dieselReference
Mercedes-Benz 6.0L 6-cyl dieselReference
Fuel tank120.0 LReference
Engine74.6 kWReference
Mercedes-Benz OM366Reference
nautral dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.7 LReference
Bore/Stroke97 x 128 mmReference
Power70.8 kWReference
Rated RPM2600Reference
Mercedes-Benz OM352Reference
dieselReference
Displacement6.0 LReference
Bore/Stroke98 x 133 mmReference
Power74.6 kWReference
Rated RPM2400Reference
Torque350.1 NmReference
Torque RPM1500Reference
Transmission
16-speedReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
Pump flow40.1 lpmReference
Rear lift4700 kgReference
Rear PTO Type540, 1000Reference
Dimensions
Wheelbase259 cmReference
Weight4500 kgReference
Front tire16.9R26Reference
Rear tire16.9R26Reference
Ag front16.9R26Reference
Ag rear16.9R26Reference
Length445 cmReference
Height286 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
