Tractor · 1976Unverified
Mercedes-Benz Trac 1100
Mercedes-Benz Trac 1100 — Model year 1976-19871987-1991 · 110 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
110 hp
Weight
5600 kg
Hover a source tag to verify
Overview
ManufacturerMercedes-BenzReference
Four-wheel Drive (4WD) tractorReference
Drive4x4 4WDReference
Final drivesexternal planetaryReference
Power steeringReference
Hydraulic drum brakesReference
Trailer brakespneumaticReference
Cab standard. Optional air-condtioning.Reference
Engine
Mercedes-Benz 5.7L 6-cyl dieselReference
Fuel tank169.9 LReference
Engine82.0 kWReference
Mercedes-Benz OM352Reference
nautral dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.7 LReference
Bore/Stroke97 x 128 mmReference
Power82.0 kWReference
Rated RPM2600Reference
Torque375.1 NmReference
Torque RPM1500Reference
Starter volts12Reference
Transmission
14-speed synchronizedReference
22-speed creeperReference
TypesynchronizedReference
Gears14 forward and reverseReference
Clutch310mm dry discReference
TypecreeperReference
Gears22 forward and reverseReference
PTO & Hydraulics
Pressure200.0 barReference
Pump flow45.0 lpmReference
Pump flow60.2 lpmReference
Rear TypeIIReference
Rear lift4078 kgReference
Rear lift6119 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Front PTOindependentReference
Front PTO Type540/1000Reference
Dimensions
Wheelbase264 cmReference
Weight5600 kgReference
Front tire14.9-30Reference
Rear tire14.9-30Reference
Ag front14.9-30Reference
Ag rear14.9-30Reference
Ag front16.9-30Reference
Ag front9.5-36Reference
Ag front18.4-30Reference
Ag rear16.9-30Reference
Ag rear9.5-36Reference
Ag rear18.4-30Reference
Length466 cmReference
Height (cab)294 cmReference
Ground clearance53 cmReference
Front tread180 to 199 cmReference
Rear tread180 to 199 cmReference
Shipping5600 kgReference
Max front axle4680 kgReference
Max rear axle4680 kgReference
Electrical
Charging systemalternatorReference
Charging amps35Reference
Charging volts14Reference
Battery volts12Reference
Battery AH110Reference
Capacities
Max capacity9000 kgReference
Speeds
With 14.9-30 tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
