Tractor · 1976Unverified
Mercedes-Benz Trac 1300
Mercedes-Benz Trac 1300 — Model year 1976-19871987-1991 · 125 hp. Reference specifications; pending source verification.
The Mercedes-Benz Trac 1300 is a tractor model with a 125 hp rating, categorising it among the more powerful machines in its class. It was produced from 1976 to 1991 and features a 6-cylinder turbocharged diesel liquid-cooled engine driving through four-wheel drive with a 14-speed gearbox. The listed weight is 5800 kg, and it is suited to tasks involving approximately 200–800 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
125 hp
Weight
5800 kg
Catalogue coverage
Variants represented
2
Richest spec table
53 rows
Recorded power
125 hp
Recorded weight
5800 kg
Transmissions
14-speed synchronized
Production years
1976-1991
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerMercedes-BenzReference
Four-wheel Drive (4WD) tractorReference
Drive4x4 4WDReference
Power steeringReference
Hydraulic drum brakesReference
Cab standard. Air-conditioning optional.Reference
Engine
Mercedes 5.7L 6-cyl dieselReference
Fuel tank169.9 LReference
Engine93.2 kWReference
Mercedes OM 352AReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.7 LReference
Bore/Stroke97 x 128 mmReference
Power93.2 kWReference
Rated RPM2600Reference
Torque392.0 NmReference
Torque RPM1600Reference
Starter volts12Reference
Transmission
14-speed synchronizedReference
22-speed creeperReference
TypesynchronizedReference
Gears14 forward and reverseReference
Clutch310mm dry discReference
TypecreeperReference
Gears22 forward and reverseReference
PTO & Hydraulics
Pump flow60.2 lpmReference
Rear TypeII/IIIReference
Rear lift5000 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase264 cmReference
Weight5800 kgReference
Front tire18.4-30Reference
Rear tire18.4-30Reference
Ag front18.4-30Reference
Ag rear18.4-30Reference
Ag front14.9-30Reference
Ag front9.5-36Reference
Ag rear14.9-30Reference
Ag rear9.5-36Reference
Length466 cmReference
Height (cab)290 cmReference
Shipping weight5800 kgReference
Max weight10000 kgReference
Ground clearance50 cmReference
Front tread180 to 199 cmReference
Rear tread180 to 199 cmReference
Electrical
Charging systemalternatorReference
Charging amps35Reference
Charging volts14Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
