Tractor · 1980Unverified
Mercedes-Benz Trac 1500
Mercedes-Benz Trac 1500 — Four-wheel Drive (4WD) tractor · 150 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
150 hp
Weight
6221 kg
Hover a source tag to verify
Overview
ManufacturerMercedes-BenzReference
Four-wheel Drive (4WD) tractorReference
Drive4x4 4WDReference
Steeringhydrostatic powerReference
Engine
Mercedes 5.7L 6-cyl dieselReference
Fuel tank169.9 LReference
Engine111.9 kWReference
Mercedes OM 352AReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.7 LReference
Bore/Stroke97 x 128 mmReference
Power111.9 kWReference
Rated RPM2400Reference
Torque490.1 NmReference
Torque RPM1800Reference
Transmission
14-speedReference
Gears14 forward and reverseReference
PTO & Hydraulics
Pump flow45.0 lpmReference
Rear lift6500 kgReference
Rear PTO Type540, 1000Reference
Dimensions
Wheelbase264 cmReference
Weight6221 kgReference
Front tire18.4R34Reference
Rear tire18.4R34Reference
Ag front18.4R34Reference
Ag rear18.4R34Reference
Length467 cmReference
Height292 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
