The Merlin TDX140 is a tractor with a rated output of 140 hp, ranking it among the higher-powered machines in its class. It is powered by a 6-cylinder turbocharged diesel liquid-cooled engine, which drives four-wheel drive via a hydrostatic transmission. The listed weight of the Merlin TDX140 is 6699 kg, and it is suited for tasks covering around 200–800 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
140 hp
Weight
6699 kg
Catalogue coverage
Variants represented
2
Richest spec table
34 rows
Recorded power
140 hp
Recorded weight
6699 kg
Transmissions
16-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerMerlinReference
Built in AustraliaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
standard with heat and A/CReference
Engine
Perkins 6.0L 6-cyl dieselReference
Fuel tank249.8 LReference
Engine104.4 kWReference
Perkins 1006-6TReference
turbo dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.0 LReference
Bore/Stroke100 x 127 mmReference
Power104.4 kWReference
Rated RPM2400Reference
Torque540.1 NmReference
Transmission
16-speedReference
TransmissionshuttleReference
Gears16 forward and reverseReference
PTO & Hydraulics
Valves3Reference
Total flow79.9 lpmReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase268 cmReference
Weight6699 kgReference
Front tire14.9-26Reference
Rear tire18.4-38Reference
Ag front14.9-26Reference
Ag rear18.4-38Reference
Length407 cmReference
Width228 cmReference
Height320 cmReference
Ground clearance44 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
