The Merlin TDX85 is a tractor with a rated engine power of 85 hp, positioning it approximately in the middle of its class in terms of power output. It features a 4-cylinder turbocharged diesel liquid-cooled engine, which transmits power to all four wheels via a hydrostatic transmission. The tractor's listed weight is 3749 kg, and it is designed for tasks covering approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
85 hp
Weight
3749 kg
Catalogue coverage
Variants represented
2
Richest spec table
36 rows
Recorded power
85 hp
Recorded weight
3749 kg
Transmissions
8-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerMerlinReference
Built in AustraliaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
standard with heat and A/CReference
Engine
Perkins 4.0L 4-cyl dieselReference
Fuel tank149.9 LReference
Engine63.4 kWReference
Perkins 1004-4TRReference
turbo dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke100 x 127 mmReference
Power63.4 kWReference
Rated RPM2400Reference
Torque340.1 NmReference
Transmission
8-speedReference
16-speedReference
TransmissionshuttleReference
Gears8 forward and reverseReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
Total flow40.1 lpmReference
Total flow60.2 lpmReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase218 cmReference
Weight3749 kgReference
Front tire11.2-24Reference
Rear tire16.9-34Reference
Ag front11.2-24Reference
Ag rear16.9-34Reference
Length407 cmReference
Width191 cmReference
Height280 cmReference
Ground clearance38 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
