Tractor · 1920Unverified

Minneapolis 12-25

Name: Minneapolis 12-25
Brand: Minneapolis

Minneapolis 12-25 — Standard-tread tractor · 12 hp. Reference specifications; pending source verification.

The Minneapolis 12-25 is a compact tractor with a rated output of 12 horsepower. It was manufactured between 1920 and 1926, with a 4-cylinder liquid-cooled engine that powers a two-wheel drive configuration via a 2-speed gearbox. The tractor's listed weight is 2903 kg, and it is suited to handling areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

12 hp

Max power

12.1 kW

Weight

2903 kg

Catalogue coverage

Variants represented

Richest spec table

37 rows

Recorded power

12 hp

Recorded weight

2903 kg

Transmissions

2-speed gear

Production years

1920-1926

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMinneapolis (a part of Minneapolis Threshing Machine Company)Reference

Standard-tread tractorReference

Built in Hopkins, Minnesota, USAReference

Two-wheel driveReference

Manual steeringReference

Engine

Minneapolis Threshing Machine 7.3L 4-cyl keroseneReference

Drawbar (claimed)8.9 kWReference

Belt (claimed)18.6 kWReference

Plows3 (14-inch)Reference

Drawbar (tested)12.1 kWReference

Belt (tested)19.6 kWReference

Minneapolis Threshing MachineReference

keroseneReference

4-cylinderReference

liquid-cooledReference

Displacement7.3 LReference

Bore/Stroke114 x 178 mmReference

Rated RPM750Reference

Starter typehand crankReference

Belt power (max)19.6 kWReference

Max power12.1 kWReference

Transmission

2-speed gearReference

TypegearReference

Gears2 forward and 1 reverseReference

Dimensions

Weight2903 kgReference

Rear tire56x12Reference

Ag rear56x12 (steel)Reference

Length421 cmReference

Width218 cmReference

Height162 cmReference

Capacities

Diameter38 cmReference

Width16 cmReference

RPM750Reference

Test results

May 17 - June 3, 1920Link: Nebraska Tractor Test 13 fileReference

Belt fuel use (max)15.9 l/hourReference

Drawbar performanceReference

Max pull1293 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
