Tractor · 1920Unverified

Minneapolis 12-25

Minneapolis 12-25 — Standard-tread tractor · 12 hp. Reference specifications; pending source verification.

The Minneapolis 12-25 is a compact tractor with a rated output of 12 horsepower. It was manufactured between 1920 and 1926, with a 4-cylinder liquid-cooled engine that powers a two-wheel drive configuration via a 2-speed gearbox. The tractor's listed weight is 2903 kg, and it is suited to handling areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
12 hp
Max power
12.1 kW
Weight
2903 kg

Catalogue coverage

Variants represented
2
Richest spec table
37 rows
Recorded power
12 hp
Recorded weight
2903 kg
Transmissions
2-speed gear
Production years
1920-1926
Verified variants
0

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMinneapolis (a part of Minneapolis Threshing Machine Company)Reference
Standard-tread tractorReference
Built in Hopkins, Minnesota, USAReference
Two-wheel driveReference
Manual steeringReference

Engine

Minneapolis Threshing Machine 7.3L 4-cyl keroseneReference
Drawbar (claimed)8.9 kWReference
Belt (claimed)18.6 kWReference
Plows3 (14-inch)Reference
Drawbar (tested)12.1 kWReference
Belt (tested)19.6 kWReference
Minneapolis Threshing MachineReference
keroseneReference
4-cylinderReference
liquid-cooledReference
Displacement7.3 LReference
Bore/Stroke114 x 178 mmReference
Rated RPM750Reference
Starter typehand crankReference
Belt power (max)19.6 kWReference
Max power12.1 kWReference

Transmission

2-speed gearReference
TypegearReference
Gears2 forward and 1 reverseReference

Dimensions

Weight2903 kgReference
Rear tire56x12Reference
Ag rear56x12 (steel)Reference
Length421 cmReference
Width218 cmReference
Height162 cmReference

Capacities

Diameter38 cmReference
Width16 cmReference
RPM750Reference

Test results

May 17 - June 3, 1920Link: Nebraska Tractor Test 13 fileReference
Belt fuel use (max)15.9 l/hourReference
Drawbar performanceReference
Max pull1293 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
