Tractor · 1958Unverified
Minneapolis-Moline 2 Star Golden Kat
Minneapolis-Moline 2 Star Golden Kat — Agricultural Crawler tractor · 57 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
57 hp
Weight
4141 kg
Hover a source tag to verify
Overview
ManufacturerMinneapolis-MolineReference
Agricultural Crawler tractorReference
Built in Minneapolis, Minnesota, USAReference
Total built51Reference
DrivecrawlerReference
Open operator station.Reference
Engine
Minneapolis-Moline 3.4L 4-cyl gasolineReference
Engine42.5 kWReference
Minneapolis-Moline 206K-4Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement3.4 LReference
Bore/Stroke92 x 127 mmReference
Power42.5 kWReference
Compression7.3:1Reference
Rated RPM1900Reference
Firing order1-3-4-2Reference
StarterelectricReference
Starter volts12Reference
Transmission
5-speed power shuttleReference
Typepower shuttleReference
Gears5 forward and reverseReference
PTO & Hydraulics
Typeopen centerReference
Pump flow94.6 lpmReference
Rear PTOtransmissionReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1845Reference
Dimensions
Weight4141 kgReference
12-inch tracksReference
Gauge132 cmReference
Minneapolis-Moline 2 Star Tracks
Width30 cmReference
Length on ground189 cmReference
Area on ground1.2 m²Reference
Width35 cmReference
Area on ground1.3 m²Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
