Tractor · 1950Unverified
Minneapolis-Moline BF
Minneapolis-Moline BF · 27 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
27 hp
Max power
18.0 kW
Weight
1312 kg
Hover a source tag to verify
Overview
ManufacturerMinneapolis-MolineReference
Total built7,627 (BF and Avery R)Reference
The Minneapolis-Moline BF is the Avery model R. When Minneapolis-Moline took over the B.F. Avery factory in 1951, the R was in production. Because Minneapolis-Moline had their own model R, they renamed the Avery to the BF. It was available in single-front wheel, row-crop wide-front (BFW), row-crop tricycle front (BFD), standard (BFS), and high-crop (BFH) configurations.Reference
Two-wheel driveReference
SteeringmanualReference
SteeringpowerReference
Differential mechanical contracting band brakesReference
Open operator station.Reference
Variants
BFWrow-crop, wide-frontReference
BFDrow-crop, tricycle frontReference
BFSstandard frontReference
BFHhigh-cropReference
Engine
Hercules 2.2L 4-cyl gasolineReference
Fuel tank45.4 LReference
Belt (claimed)20.5 kWReference
Drawbar (tested)18.0 kWReference
Belt (tested)20.2 kWReference
Hercules IXB3Reference
gasolineReference
4-cylinderReference
liquid-cooled vertical L-headReference
Displacement2.2 LReference
Bore/Stroke83 x 102 mmReference
Compression6.8:1Reference
Rated RPM1800Reference
Starter typeelectricReference
Coolant capacity10.4 LReference
Belt power (max)20.2 kWReference
Max power18.0 kWReference
Transmission
4-speed unsynchronized gearReference
Typeunsynchronized gearReference
Gears4 forward and 1 reverseReference
Clutch228.6mm dry discReference
PTO & Hydraulics
Rear TypeoptionalReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase200 cmReference
Weight1312 kgReference
Front tire4.00-16Reference
Rear tire10.00-28Reference
Ag front4.00-16Reference
Ag front5.00-15Reference
Ag rear10.00-28Reference
Length297 cmReference
Height (hood)149 cmReference
Height (exhaust)193 cmReference
Operating weight1312 kgReference
Ballasted weight2102 kgReference
BF Serial Numbers
1950R500 (Avery R)Reference
1951R1839 (Avery R)Reference
1952R4460 (Avery R)Reference
1953R6538 (BFW)Reference
195357700001 (BFD)Reference
195357600001 (BFS)Reference
195358000001 (BFH)Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter25 cmReference
Width16 cmReference
RPM3040Reference
Speed353.57 meters/minReference
Test results
Gasoline 4-speed 2WDOctober 22 - 27, 1951Link: Nebraska Tractor Test 469 fileReference
Belt fuel use (max)10.6 l/hourReference
Drawbar performanceReference
Gear 3 used for power test.Reference
Max pull1236 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
