Tractor · 1962Unverified

Minneapolis-Moline G705

Name: Minneapolis-Moline G705
Brand: Minneapolis-Moline

Minneapolis-Moline G705 — Standard-tread tractor · 101 hp. Reference specifications; pending source verification.

The Minneapolis-Moline G705 is a tractor with an approximate engine rating of 101 hp, typical for its class. It was manufactured from 1962 to 1965. The G705 features a 6-cylinder diesel liquid-cooled engine, paired with a 5-speed gearbox and four-wheel drive. Its operating weight ranges from 7617 to 8155 pounds, making it suitable for land areas of 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

101 hp

Max power

67.7 kW

Weight

7617 to 8155 pounds

Catalogue coverage

Variants represented

Richest spec table

99 rows

Recorded power

101 hp

Transmissions

5-speed unsynchronized gear

Production years

1962-1965

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMinneapolis-MolineReference

Standard-tread tractorReference

Built in Hopkins, Minnesota, USAReference

Original price was $7,000 in 1965Reference

Two-wheel driveReference

Power steeringReference

Differential disc brakesReference

Open operator station. Cab optional with available air-conditioning.Reference

Variants

G7052WDReference

G7064WDReference

Engine

Minneapolis-Moline 8.3L 6-cyl dieselReference

Minneapolis-Moline 8.3L 6-cyl LP gasReference

Diesel Fuel tank143.8 LReference

LP-gas Fuel tank155.9 LReference

Engine83.5 kWReference

Drawbar (tested)67.7 kWReference

Minneapolis-MolineReference

dieselReference

6-cylinderReference

liquid-cooled inlineReference

Displacement8.3 LReference

Bore/Stroke117 x 127 mmReference

Power80.5 kWReference

Air cleaneroil bathReference

Compression14.8:1Reference

Rated RPM1600Reference

Starter volts12Reference

Oil capacity13.2 LReference

Coolant capacity47.3 LReference

LP gasReference

Power83.5 kWReference

Compression8.0:1Reference

Power at rated engine speed75.3 kWReference

Max power67.7 kWReference

Power at rated engine speed75.4 kWReference

Max power67.2 kWReference

Transmission

5-speed unsynchronized gearReference

Typeunsynchronized gearReference

Gears5 forward and 1 reverseReference

Clutchdry discReference

Oil capacity49.2 LReference

PTO & Hydraulics

Diesel PTO (claimed)68.6 kWReference

LP-gas PTO (claimed)70.8 kWReference

PTO (tested)75.4 kWReference

Typeopen centerReference

Valves2Reference

Rear PTOliveReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@1200Reference

Power at rated PTO speed60.8 kWReference

Power at rated PTO speed61.2 kWReference

Dimensions

Wheelbase243 cmReference

Weight7617 to 8155 poundsReference

Front tire7.50-18Reference

Rear tire18.4-34Reference

Ag front7.50-18Reference

Ag rear18.4-34Reference

Ag rear23.1-26Reference

Length267 cmReference

Width208 cmReference

Height (steering wheel)200 cmReference

Height (exhaust)244 cmReference

Clearance (front axle)43 cmReference

Clearance (rear axle)66 cmReference

Front tread137 cmReference

Rear tread163 cmReference

Diesel Shipping3477 kgReference

LP-gas Shipping3455 kgReference

LP-gas Operating3621 kgReference

Diesel Operating3699 kgReference

Ballasted6853 kgReference

G705 Serial Number Location

Serial number plate on the right side of the Minneapolis-Moline G705 tractor frame, ahead of the operator platform and below the battery tray.Reference

G705 Serial Numbers

196223800001 (LP)Reference

196323800079 (LP)Reference

196423800591 (LP)Reference

196523801093 (LP)Reference

Final23801223 (LP)Reference

196223900050 (diesel)Reference

196323900051 (diesel)Reference

196423900899 (diesel)Reference

196523901869 (diesel)Reference

Final23902094 (diesel)Reference

FAQ: How to read a serial number table.Reference

Test results

NTTL 835: diesel 5-speed 2WDReference

NTTL 836: LP gas 5-speed 2WDReference

Diesel 5-speed 2WDApril 19 - 30, 1963Link: Nebraska Tractor Test 835 fileReference

PTO performanceReference

Fuel use28.0 l/hourReference

Fuel use21.6 l/hourReference

Drawbar performanceReference

Gear 3 used for power test.Reference

Max pull5146 kgReference

Gear 1 used for pull test.Reference

LP gas 5-speed 2WDApril 24 - May 1, 1963Link: Nebraska Tractor Test 836 fileReference

Fuel use43.5 l/hourReference

Fuel use34.1 l/hourReference

Fuel use43.1 l/hourReference

Max pull5185 kgReference

Speeds

With 18.4-34 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
