Industrial Tractor · 1964Unverified
Minneapolis-Moline Jet Star 3
Minneapolis-Moline Jet Star 3 — Industrial tractor · 44 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
44 hp
Hover a source tag to verify
Overview
ManufacturerMinneapolis-MolineReference
Industrial tractorReference
Built in Minneapolis, Minnesota, USAReference
Two-wheel driveReference
SteeringmanualReference
Steeringhydrostatic power optionalReference
Disc brakesReference
Open operator station.Reference
Engine
Minneapolis-Moline 3.4L 4-cyl gasolineReference
Minneapolis-Moline 3.4L 4-cyl dieselReference
Minneapolis-MolineReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement3.4 LReference
Bore/Stroke92 x 127 mmReference
Air cleaneroil bathReference
Rated RPM1750Reference
Starter volts12Reference
dieselReference
Transmission
10-speed partial power shiftReference
5-speedReference
TransmissionAmpli-TorcReference
Typepartial power shiftReference
Gears10 forward and 2 reverseReference
TransmissiongearReference
Gears5 forward and 1 reverseReference
TransmissionshuttleReference
Gears5 forward and reverseReference
PTO & Hydraulics
PTO (claimed)32.8 kWReference
Rear TypeIIReference
Rear PTOindependentReference
Rear PTO Type540Reference
Jet Star 3 Serial Number Location
Right side of tractor frame, near brake pedals.Reference
Jet Star 3 Serial Numbers
196630900001 (diesel)Reference
Final30900050 (diesel)Reference
FAQ: How to read a serial number table.Reference
Dimensions
Ag front5.50-16Reference
Ag rear12.4-28Reference
Front tread127 to 198 cmReference
Rear tread142 to 213 cmReference
Speeds
With 12.4-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
