Tractor · 1963Unverified
Minneapolis-Moline M-602
Minneapolis-Moline M-602 — Row-Crop tractor · 64 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
64 hp
Weight
6080 to 6600 pounds
Hover a source tag to verify
Overview
ManufacturerMinneapolis-MolineReference
Row-Crop tractorReference
Built in Minneapolis, Minnesota, USAReference
Total built4,729Reference
Total built2,957 (gas/LP)Reference
Total built1,772 (diesel)Reference
Original price was $5,100 in 1964Reference
Two-wheel driveReference
Power steeringReference
Open operator station.Reference
Variants
M-602UtricycleReference
M-602Ewide-frontReference
M-602Nsingle frontReference
M-602SstandardReference
M-6044WDReference
Engine
Minneapolis-Moline 5.5L 4-cyl gasolineReference
Minneapolis-Moline 5.5L 4-cyl dieselReference
Minneapolis-Moline 5.5L 4-cyl LP gasReference
Fuel tank85.2 LReference
Fuel tank117.3 LReference
Diesel Drawbar (claimed)38.0 kWReference
Gas Drawbar (claimed)38.8 kWReference
LP-gas Drawbar (claimed)40.3 kWReference
Minneapolis-Moline 336-4Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement5.5 LReference
Bore/Stroke117 x 127 mmReference
Air cleaneroil bathReference
Rated RPM1500Reference
Minneapolis-MolineReference
dieselReference
LP gasReference
Transmission
10-speed two-speed power shiftReference
TransmissionAmpli-TorcReference
Typetwo-speed power shiftReference
Gears10 forward and 2 reverseReference
PTO & Hydraulics
Diesel PTO (claimed)47.7 kWReference
Gas PTO (claimed)48.5 kWReference
LP-gas PTO (claimed)49.2 kWReference
Rear TypeIIReference
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
U Wheelbase238 cmReference
E Wheelbase256 cmReference
N Wheelbase238 cmReference
Weight6080 to 6600 poundsReference
Front tire6.00-16Reference
Rear tire15.5-38Reference
Ag front6.00-16Reference
N Ag front9.00-10Reference
Ag rear15.5-38Reference
U Length355 cmReference
E Length373 cmReference
N Length347 cmReference
Width200 cmReference
Height (steering wheel)182 cmReference
Clearance (front axle)40 cmReference
Clearance (rear axle)66 cmReference
Clearance (drawbar)38 cmReference
U Front tread20/33 cmReference
E Front tread132 to 193 cmReference
Rear tread152 to 223 cmReference
U gas Operating2812 kgReference
U diesel Operating2880 kgReference
U LP-gas Operating2903 kgReference
E gas Operating2903 kgReference
E diesel Operating2971 kgReference
E LP-gas Operating2993 kgReference
N gas Operating2757 kgReference
N diesel Operating2825 kgReference
N LP-gas Operating2848 kgReference
Minneapolis-Moline M-602 attachments
front-end loaderReference
M-602 Serial Number Location
Right side of tractor frame, near brake pedals.Reference
M-602 Serial Numbers
196326600001 (gas)Reference
196426601276 (gas)Reference
Final26602957 (gas)Reference
196226700001 (diesel)Reference
196326700743 (diesel)Reference
Final26701772 (diesel)Reference
FAQ: How to read a serial number table.Reference
Speeds
With 15.5-38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
