Lawn Tractor · 1964Unverified
Minneapolis-Moline Town & Country 108
Minneapolis-Moline Town & Country 108 — Garden tractor · 8 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
8 hp
Hover a source tag to verify
Overview
DistributorMinneapolis-MolineReference
ManufacturerJacobsenReference
Garden tractorReference
Built in Racine, Wisconsin, USAReference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Engine
8HP Kohler 305cc 1-cyl gasolineReference
Fuel tank4.7 LReference
Kohler K181SReference
gasolineReference
1-cylinderReference
air-cooledReference
Displacement18.63 ciReference
Bore/Stroke75 x 70 mmReference
Power (gross)6.0 kWReference
Air cleanerdryReference
Rated RPM3600Reference
Starter volts12Reference
Oil capacity1.2 LReference
Transmission
3-speed gearReference
Typebelt-driven gearReference
Gears3 forward and 1 reverseReference
Clutchidler pulleyReference
1Clutch/brakeReference
2ThrottleReference
3Gear shiftReference
4Parking brakeReference
Dimensions
Wheelbase106 cmReference
Front tire4.80/4.00-8Reference
Rear tire6.00-12Reference
Lawn/turf front4.80/4.00-8Reference
Lawn/turf rear6.00-12Reference
Length154 cmReference
Width83 cmReference
Ground clearance29 cmReference
Clearance (front axle)22 cmReference
Clearance (rear axle)17 cmReference
Steering wheel96 cmReference
Minneapolis-Moline 108 attachments
36" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
108 Serial Number Location
Front-left of tractor, above front axle.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
36" mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
36" Mower deck
Typemid-mount Minneapolis-MolineReference
Cutting width91 cmReference
Minneapolis-Moline 108 Height
81 cmReference
Hood87 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
