Tractor · 1951Unverified
Minneapolis-Moline V
Minneapolis-Moline V — Utility tractor. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Weight
775 kg
Hover a source tag to verify
Overview
ManufacturerMinneapolis-MolineReference
Utility tractorReference
Two-wheel driveReference
SteeringmanualReference
Open operator station.Reference
Engine
Hercules 1.1L 4-cyl gasolineReference
Fuel tank26.5 LReference
Plows1Reference
Hercules ZXB-3Reference
gasolineReference
4-cylinderReference
liquid thermosiphon-cooledReference
Displacement1.1 LReference
Bore/Stroke67 x 76 mmReference
Air cleaneroil bathReference
Rated RPM1800Reference
Starter typemanualReference
Starter typeelectricReference
Oil capacity2.8 LReference
Coolant capacity5.7 LReference
Transmission
3-speed unsynchronized gearReference
Typeunsynchronized gearReference
Gears3 forward and 1 reverseReference
Oil capacity2.8 LReference
PTO & Hydraulics
Rear PTO Type540Reference
Dimensions
Wheelbase187 cmReference
Weight775 kgReference
Front tire4.00x15Reference
Rear tire8x24Reference
Ag front4.00x15Reference
Ag rear8x24Reference
Ag rear9x24Reference
Length266 cmReference
Width129 cmReference
Height (steering wheel)155 cmReference
Height (hood)130 cmReference
Shipping weight775 kgReference
Ground clearance58 cmReference
V Serial Numbers
19516V186Reference
19526V422Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter15 cmReference
Width13 cmReference
RPM1990Reference
Speed944.88 meters/minReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
