The Minneapolis-Moline ZTS is a tractor model with a rating of approximately 25 hp, positioning it at the lower end of its class. Production of the Minneapolis-Moline ZTS occurred between 1937 and 1947. The tractor features a 4-cylinder petrol liquid-cooled engine, paired with two-wheel drive and a 5-speed gearbox. It is suitable for operations covering up to 200 ac.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Catalogue coverage
Variants represented
2
Richest spec table
39 rows
Recorded power
25 hp
Transmissions
5-speed unsynchronized gear
Production years
1937-1947
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerMinneapolis-MolineReference
Standard-tread tractorReference
Built in Minneapolis, Minnesota, USAReference
Two-wheel driveReference
SteeringmanualReference
Drum brakesReference
Open operator station.Reference
Variants
ZTUrow-cropReference
ZTSstandard frontReference
ZTIindustrialReference
Engine
Minneapolis-Moline 3.0L 4-cyl gasolineReference
Drawbar (claimed)11.9 kWReference
Minneapolis-Moline REReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement3.0 LReference
Bore/Stroke92 x 114 mmReference
Compression5.75:1Reference
Rated RPM1500Reference
Firing order1-3-4-2Reference
Transmission
5-speed unsynchronized gearReference
Typeunsynchronized gearReference
Gears5 forward and 1 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)18.6 kWReference
ZTS Serial Numbers
1937610001Reference
1938610036Reference
1939610389Reference
1940610685Reference
1941611088Reference
1942611343Reference
1943611447Reference
1944611966Reference
1945612486Reference
1946612886Reference
1947613086Reference
Final613490Reference
FAQ: How to read a serial number table.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
